Features:
- Proximity Probe Housing Assemblies
- Aluminum body with 304 stainless steel sleeve
- 21000, 24701, and 164818 Proximity Probe Housing Assemblies
The 21000 and 24701 Proximity Probe Housing Assemblies are available with Canadian Standards Association (CSA) approvals. They are rated explosion proof for hazardous areas. Bently Nevada offers a probe support and oil seal (part number 37948-01) for long sleeves that must go through an inner bearing housing.
To externally mount proximity probes, use one of these allmetal Proximity Probe Housing Assemblies: 21000 aluminum probe housing assembly; 24701 stainless steel probe housing assembly The 21000 and 24701 Proximity Probe Housing Assemblies consist of the following parts:A dome cover that screws into the body of the housing; Threaded ports for conduit connections; A probe sleeve of optional length; 0-rings; A reverse mount proximity probe; A thread seal; Optional conduit fittings; An optional standoff adapter.
The 21000-00-00-60-028-02-02 Bently Nevada Proximity Probe Housing Assemblies may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 21000-00-00-60-028-02-02 Proximity Probe Housing Assemblies Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Model: 21000-00-00-60-028-02-02
- Warranty: One-year warranty
- Condition: Brand new, original, in stock
- Product Family: 21000, 24701, and 164818 Proximity Probe Housing Assemblies
Proximity Probe Housing Assemblies
21000-Axx-Bxx-Cxx-Dxxx-Exx-Fxx
A: Probe with Connector
00: Probe not required
14: 420 nuclear
16: 3300 XL 8mm probe
26: 3300 XL NSv probe
27: 3300 XL NSv probe, selectable hazardous area approvals
28: 3300 XL 8mm probe, selectable hazardous area approvals
29: 3300 XL 11mm probe
30: 3300 XL 11mm probe, selectable hazardous area approvals
31: 3300 XL NSv probe with connector protector
32: 3300 XL NSv probe with connector protector, selectable hazardous area approvals
33: 3300 XL 8mm probe with connector protector
34: 3300 XL 8mm probe with connector protector, selectable hazardous area approvals
35: 3300 XL 11mm probe with connector protector
36: 3300 XL 11mm probe with connector protector, selectable hazardous area approvals
37: 3300 XL 8mm probe, ETR, selectable hazardous area approvals (available for 21000 only)
B: Probe Cable Length
00: Probe cable not required
05: 0.5 m (20 in)
10: 1.0 m (39 in)
12: 12.0 in
18: 18.0 in
24: 24.0 in
30: 30.0 in
36: 36.0 in
C: Standoff Adapter (Option C Dimension)
15: Minimum length 1.5 in (38 mm)
75: Maximum length 7.5 in (191 mm)
Examples
1.5 in (38 mm) = 15
No standoff adapter = 00
D: Probe Penetration (Option D Dimension)
10: Minimum length 1.0 in (25.4 mm)
Examples
3.7 in (94 mm) = 037
22.4 in (569 mm) = 224
E: Fittings
00: Without fittings
01: One 3/4-14 NPT explosion-proof fitting; One 3/4-14 NPT plug
02: Two 3/4-14 NPT explosion-proof fittings
03:One 3/4-14 NPT plug; One 3/4-14 to 1/2-14 NPT reducer; One cable seal grip with grommets for; the following cable sizes:
• 1/8 to 3/16 inches
• 1/4 to 5/16 inches
• 5/16 to 3/8 inches
04: One 3/4-14 NPT plug only
F: Mounting Thread
01: As cast without threads
02: 3/4-14 NPT
04: 1/2-14 BSP
In the overall safety monitoring and system integration architecture, this protective enclosure component, once correctly assembled with the probe on-site, provides all-weather environmental protection capabilities. Its shell meets the high-level CSA Type 4 standard for splash, dust, and explosion protection (Weatherproof Enclosure), and its structural design fully complies with the stringent technical specifications of the American Petroleum Institute (API) 670 standard for machinery monitoring hardware. The coaxial cable safely led from this protective enclosure, after being connected to the preamplifier on-site, ultimately connects the linear voltage signal to the Bently Nevada 3500 machinery protection system. It is widely deployed in harsh heavy industrial environments such as oil and gas, large-scale chemical plants, and power plants, characterized by high temperatures, high oil content, and flammable and explosive materials, ensuring the absolute stability and safety of the underlying physical monitoring signals.
