Features:
- 3300 XL 8mm Eddy Current Bearing Vibration/Displacement Sensor Probe (3/8-24 Thread Reverse Mount)
- Non-standard or Custom (MOD) Specific Product Material Code
- Coaxial ClickLoc Mini Connector with Connector Protector
The Bently Nevada 168209-0317-127-90-05-01 is a high-performance 3300 XL 8mm eddy current displacement sensor probe designed specifically for industrial rotating machinery. Its core function is to achieve high-precision, non-contact, continuous monitoring of mechanical conditions. When used with a preamplifier and extension cable, it can capture micron-level dynamic changes in critical equipment (such as steam turbines, compressors, large water pumps, and fans) in industries like power plants, petrochemicals, and metallurgy, providing highly reliable raw signal input for condition monitoring and safety protection loops such as the Bently Nevada 3500 system.
In actual industrial settings, this probe is primarily responsible for measuring the radial vibration, static axial displacement (thrust position), and key phase (speed and phase) signals of the shaft. It possesses strong resistance to environmental interference and can operate stably under high temperature, high pressure, and in harsh environments such as those filled with lubricating oil. By accurately measuring the relative distance change between the shaft and its end face, it can help maintenance engineers detect early mechanical faults such as bearing wear, shaft misalignment, and rotor imbalance, preventing catastrophic equipment damage.
The 168209-0317-127-90-05-01 Bently Nevada Eddy current displacement sensor probe may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 168209-0317-127-90-05-01 Eddy current displacement sensor probe INFO(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Model: 168209-0317-127-90-05-01
- Warranty: One-year warranty
- Condition: Brand new, original, in stock
- Product Family: 3300 XL series 8mm special improved eddy current displacement sensor probe
In practical industrial applications, the probe itself comes with a 9.0-meter cable, eliminating the need for intermediate extension cables in the field; the end connector can be directly connected to a 9.0-meter system-specific proximity sensor inside the control box, strictly meeting the total length calibration balance requirements of the eddy current loop. The preamplifier utilizes the eddy current principle to convert the minute gap changes between the probe end face and the shaft surface into a standard 7.87 V/mm (200 mV/mil) dynamic voltage signal in real time. This signal is continuously transmitted to the Bentley 3500 monitoring cabinet, providing the most basic and reliable data foundation for millisecond-level interlocking trip protection and online condition diagnostics of high-speed industrial critical assets.
