Features:
- The documented unthreaded length is 0.0 in; confirm the installed mounting interface, available reach and mechanical clearance before replacement.
- The documented overall case length is 0.8 in; retain this dimension when checking mounting geometry, routing and compatibility with the installed hardware.
- The documented total length is 9.0 metres (29.5 feet); retain this dimension when checking mounting geometry, routing and compatibility with the installed hardware.
330171-00-08-90-01-05 is a Bently Nevada 3300 5mm Proximity Probes for the 3300 system. It measures shaft vibration or position without contact in a matched transducer chain. Key specifications: Unthreaded Length: 0.0 in; Overall Case Length: 0.8 in. Match the full order code and hardware before replacement.
The Bently Nevada 330171-00-08-90-01-05 is a Model 3300 5mm eddy current displacement probe designed for applications in confined spaces, such as between thrust bearing pads. According to its specifications, the probe features a 1/4-28 UNF threaded stainless steel housing and a PPS (polyphenylene sulfide) insulated probe tip. Key selection parameters include: no unthreaded portion, a total housing length of 0.8 inches, a total system length of 9.0 meters (approximately 29.5 feet), a miniature coaxial ClickLoc connector with a protective cap (standard cable, unarmored), and certifications from multiple international explosion-proof and safety agencies. The system is fully interchangeable with the 3300 XL extension cable and preamplifier, and accurately and reliably transmits static displacement (position) or dynamic vibration signals to the 3500 monitoring system.
The exact 330171-00-08-90-01-05 execution must be confirmed by its complete order code, condition, connected 3300 system and included scope before purchase or replacement.
Bently Nevada 330171-00-08-90-01-05 3300 5mm Proximity Probes manual (Datasheet), Link
Important Notice: Confirm the complete order code, hardware execution and connected system before replacement. Accessories, cables, calibration data, software and certificates are included only when stated in the written quotation.
Preserve every option block of 330171-00-08-90-01-05. Retained facts: Unthreaded Length: 0.0 in; Overall Case Length: 0.8 in; Total Length: 9.0 metres (29.5 feet). Mechanical length, thread, cable/connector and approval suffixes are part of the exact probe identity.
Match probe family, electrical length, extension cable and Proximitor Sensor. Confirm target material, available travel, nearby probe spacing and mounting geometry before exchange.
Set the operating gap from live bias voltage, support the cable above its bend limit and verify runout, vibration or position response against the commissioning baseline.
