- 24 Vdc to 5 Vdc/12 A converter
- The supply voltage of the FSC system is 24 Vdc
- The 10300/1/1 DC/DC converter provides the internal 5 Vdc with galvanic isolation between the two supply voltages
The FSC system operates on a 24 Vdc supply voltage, which can be supplied by the factory's 24 Vdc power supply system, and is equipped with a battery backup power supply.
The FSC system uses an internal 5 Vdc power supply to power the FSC modules. The 10300/1/1 DC/DC converter provides the internal 5 Vdc power supply and provides electrical isolation between the two supply voltages.
The 10300/1/1 Honeywell FSC Converter Module Card may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell 10300/1/1 FSC Converter Module Card Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 10300/1/1 operates based on an industrial signal interface and system-level data transmission mechanism. It acquires, processes, and standardizes field signals to achieve reliable interaction with the upper-level control system.
Internal Power Supply: Converts the factory's 24VDC power supply voltage (typically battery powered) to the 5VDC internal voltage required by the FSC system module logic circuitry.
Electrical Isolation: Provides critical electrical isolation between the external 24VDC factory power supply and internal system electronics, ensuring safe and reliable industrial operation.
Industrial Control Systems: Used as part of a Safety Instrumented System (SIS) in safety-critical environments such as oil and gas, petrochemical, power generation, and water treatment.
