- 05704-A-0145 is identified by control channels 4 independent channels within the documented System 57 gas detection configuration.
- The official specification gives detector input as 4-20 mA, which must be retained during selection.
- Commissioning must also preserve card width (1 in) and the stated connection limits.
A System 57 model 5704 control card that monitors four independent 4-20 mA gas-detector channels in a one-inch rack position. Each channel uses the common control-card architecture with local analog and alphanumeric indication and connects through the documented 5704 field interface arrangement. Selection must preserve the complete label identity, connected-equipment compatibility and manufacturer installation limits.
Manufacturer reference: official System 57 gas detection documentation.
Moore Automated supports exact-item verification and spare-part enquiries for 05704-A-0145.
Honeywell 05704-A-0145 official manufacturer document excerpt (PDF), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Confirm the complete 05704-A-0145 identity and compare control channels, detector input and card width with the installed design before approving a replacement.
Use in a System 57 5704 rack with the documented 4-20 mA detector wiring and field interface. Verify loop power, line resistance, alarm configuration and any 05704-A-0121 relay interface connection.
Back up all four channel settings, isolate the rack and detector loops, reproduce terminal assignments, configure range and alarms, then perform zero, span, fault and relay tests for every channel.
