Features:
- Product type: Programmable transmitter/control unit
- Product series: Series 1011
- Input: 3-wire potentiometer, 1 kΩ to 100 kΩ
KFG LEVEL MUL-D2 is a Series 1011 programmable transmitter/control unit for converting a three-wire potentiometer level input into standardized analog signals.
It accepts a 1 kΩ to 100 kΩ three-wire potentiometer and provides selectable 0/4–20 mA and 0/2–10 V DC outputs. Two relay outputs rated up to 500 VA at 230 V and a four-digit red LED display support local indication and alarm control.
The unit operates from 18–36 V DC or 24/115/230 V AC, supports free scaling, DIN-rail mounting and IP20/IP40 protection. Installation must follow the official Series 1011 wiring and relay-load limits.
The KFG LEVEL MUL-D2 may be supplied and supported by Moore Automated according to the official product lifecycle: Obsolete/Discontinued by OEM.
KFG LEVEL MUL-D2 Universal level transmitter and display Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, licenses and related items are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Technical details:
- Product type: Programmable transmitter/control unit
- Product series: Series 1011
- Input: 3-wire potentiometer, 1 kΩ to 100 kΩ
- Current output: 0/4–20 mA
- Voltage output: 0/2–10 V DC
- Relay outputs: 2, maximum 500 VA at 230 V
MUL-D2 combines a three-wire potentiometer interface, dual standardized analog outputs, local four-digit indication and two relay outputs in one DIN-rail control unit. Confirm the supply selection, input resistance, analog scaling and relay contact loading against the official Series 1011 documentation before wiring.
Compatibility: It is intended for Series 1011 level applications using a 1–100 kΩ three-wire potentiometer; verify supply voltage, output scaling and relay logic before substitution.
Configuration: Select the correct AC or DC supply, keep analog and relay wiring separated, use conductors up to 2.5 mm² and commission the free scaling with the process at known reference levels.
Application: It is used for level indication, analog signal conversion and two-point alarm or control duties in industrial process systems.
Lifecycle: MUL-D2 is a legacy Series 1011 product. The official document does not identify a direct drop-in successor, so replacement requires an application and wiring review.
MUL-D2 combines a three-wire potentiometer interface, dual standardized analog outputs, local four-digit indication and two relay outputs in one DIN-rail control unit. Confirm the supply selection, input resistance, analog scaling and relay contact loading against the official Series 1011 documentation before wiring.
