Features:
- PROFIBUS communication module
- It can manage up to 16 Class 1 commands and 16 Class 2 commands simultaneously
- Save time! No ladder logic to write for configuration and data transfer between module and ControlLogix processor
The SST module requires no ladder logic programming, saving you time. This configuration was created using Windows Engineering Console software, which connects via RLL (Remote Link Library) functionality, allowing remote access to the SST module for configuration and diagnostics, and is implemented using the Rockwell network architecture (Ethernet/ControlNet/DeviceNet).
The SST PB3 module comes with an Additional Profile (AOP) for easy integration into a ControlLogix system using RSLogix 5000 software. Data transfer from the SST module to the ControlLogix processor supports two modes: "Direct Mode," which allows PROFIBUS data to be mapped to the I/O processor image (496 input bytes/496 output bytes); and "Paging Mode," which allows access to 1984 input bytes and 1968 output bytes of PROFIBUS data from a user-defined data space in the Logix CPU memory.
The SST-PB3-CLX Molex Woodhead PROFIBUS communication module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Molex Woodhead SST-PB3-CLX PROFIBUS communication module INFO(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
• Control/Command of Profibus slave devices to perform tasks with strong critical time constraints
• Collect Profibus data forSupervision/Scada to monitor plant
• Bridge Rockwell networks to Siemens environment using PROFIBUS Master&Slave modes simultaneously
- 1120160018 / SST-PB3-CLX-RLL / SST™ PROFIBUS Scanner for AB ControlLogix, includes RLL
- 1120160023 / SST-PB3-CLX-RLL-CC / SST™ PROFIBUS Scanner for AB ControlLogix, coated version, includes RLL
- 1120160019 / SST-PB3-CLX-DTM / SST™ PROFIBUS Scanner for AB ControlLogix, includes RLL and CommDTM driver license
- 1120160020 / SST-PB3-CLX-DTS / SST™ CommDTM update driver license for PROFIBUS Scanner
