16 AI Paths
SPASI Match
100 ft Cable
Features:
- The documented unit function is Analog input termination, and this value must match the supplied unit.
- The documented field signal paths is 16, and this value must match the supplied unit.
- The documented compatible module architecture is SPASI analog input, and this value must match the supplied unit.
ABB NTAI06 is a Analog Input Termination Unit documented for the applicable Bailey Infi 90 system configuration. Its recorded specification includes unit function Analog input termination, field signal paths 16, compatible module architecture SPASI analog input. Correct selection depends on the complete article identity, installed equipment, mechanical or electrical interfaces and the documented configuration rather than appearance alone. Using the exact model helps maintenance teams avoid incompatible revisions, connector arrangements and application variants.
Before installing NTAI06, record the original nameplate, installed position, connected assemblies and every relevant configuration detail. Compare the supplied unit with the existing hardware and applicable ABB service documentation, isolate all affected energy sources and preserve required settings or calibration data. After installation, inspect each affected interface and complete controlled functional checks before returning the equipment to service.
The NTAI06 ABB Analog Input Termination Unit is listed as Active / Available from OEM. Current revision, availability and supplied scope are confirmed in the written quotation.
ABB NTAI06 documentation and reference links.
Important Notice: Every linked document must identify the listed model or its documented family. Confirm the complete order code, hardware revision and installed-system requirements before replacement.
NTAI06 is documented for the field-side interface for SPASI analog inputs. The unit provides 16 input paths and supports cable runs up to 100 feet.
Apply NTAI06 only with the NTAI06 termination with NKAS01 or NKAS11 cable; confirm SPASI architecture, NKAS01/NKAS11 cable, field signals, shields and terminal map.
Record the installed arrangement before service, then verify all 16 channels, signal scaling, noise level and input diagnostics after replacement.
