Features:
- Proximity Probe Housing Assemblies
- 31000 and 32000 Proximity Probe Housing Assemblies
- The 31000/32000 Proximity Probe Housing Assembly is made of polyphenylene sulfide (PPS)
When proximity probes need to be mounted inside a machine housing, the 31000/32000 type proximity probe housing assembly is recommended. This assembly is typically used for radially mounted sensors, whether for vibration or key phase measurements. Using a proximity probe housing allows for easy external access to the proximity probe and its extension cables, enabling gap adjustment or probe replacement without disassembling the machine.
The 31000/32000 type proximity probe housing assembly is made of polyphenylene sulfide (PPS), an advanced high-strength thermoplastic material with excellent corrosion resistance. Other components of the housing assembly are made of corrosion-resistant stainless steel. Versions of this housing assembly pre-installed with the 3300 XL type proximity probe and various conduit fittings are available by order.
The 31000-00-00-15-047-01-02 Bently Nevada Proximity Probe Housing Assemblies may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 31000-00-00-15-047-01-02 Proximity Probe Housing Assemblies Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Model: 31000-00-00-15-047-01-02
- Warranty: One-year warranty
- Condition: Brand new, original, in stock
- Product Family: 31000 and 32000 Proximity Probe Housing Assemblies
English Proximity Probe Housing Assemblies
31000 - Axx-Bxx-Cxx-Dxxx-Exx-Fxx
A: Probe with Connector
00: Probe not required
16: 3300 XL 8 mm probe
26: 3300 XL NSv probe
27: 3300 XL NSv probe, multiple approvals
28: 3300 XL 8 mm probe, multiple approvals
29: 3300 XL 8 mm probe, with connector protector
30: 3300 XL 8 mm probe, with connector protector, multiple approvals
31: 3300 XL NSv probe with connector protector
32: 3300 XL NSv probe with connector protector, multiple approvals
33: 3300 XL 11 mm probe
34: 3300 XL 11 mm probe, multiple approvals
35: 3300 XL 11 mm probe with connector protector
36: 3300 XL 11 mm probe with connector protector, multiple approvals
B: Probe Cable Length
00: Probe cable not required (Option A must also be 00)
05: 0.5 m (20 in)
10: 1.0 m (39 in)
C: Standoff Adapter Length (Option C Dimension)
15: Minimum length 1.5 in (38 mm)
75: Maximum length 7.5 in (191 mm)
Recommendation
Order in increments of 0.5 in (13 mm)
Examples
1.5 in (38 mm) = 15
No standoff adapter = 00
D: Probe Penetration Option (Option D Dimension)
10: Minimum length 1.0 in (25.4 mm)
Recommendation
Order in increments of 0.1 in (3 mm)
Examples
No probe sleeve = 000
3.7 in (94 mm) = 037
22.4 in (569 mm) = 224
E: Fittings
00: Without fittings
01: One 3/4-14 NPT fitting, two plugs.
02: Two 3/4-14 NPT fittings, one plug
03:
Two plugs, one 3/4-14 NPT fitting
One 3/4-14 to 1/2-14 NPT SST reducer
One cable seal grip with grommets for
the following cable sizes:
• 1/8 to 3/16 inches
• 1/4 to 5/16 inches
• 5/16 to 3/8 inches
06:
One 3/4-14 NPT fitting
One 3/4-14 NPT to 1/2-14 NPR SST
reducer
Two plugs
F: Mounting Thread
00: No outer sleeve, retainer, or retaining nut
02: 3/4-14 NPT (Required if ordering Standoff Adapter Option).
05: 7/8-14 UNF 2A
In asset protection and predictive maintenance architectures within large industrial plants, this protective enclosure, when properly assembled in the field and secured to the probe, provides robust environmental protection for sensitive internal sensing components. While not an explosion-proof hard enclosure, it can be safely deployed in intrinsically safe hazardous areas when used with certified sensor systems and intrinsically safe barriers. Its overall design fully complies with American Petroleum Institute (API) 670 standards. The signal cable securely led from the enclosure ultimately connects to a preamplifier and integrates with the Bently Nevada 3500 mechanical protection system, widely used in industries such as power, petrochemicals, and heavy metallurgy, ensuring absolute stability and data accuracy of underlying physical monitoring signals in high-temperature, high-vibration, and high-humidity environments.
