Features:
- 3300 XL Standard Extension Cable
- 3300 XL 8 mm Proximity Transducer System
- The 3300 XL probe and extension cable also reflect improvements over previous designs
The system provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.
Each 3300 XL 8 mm Transducer System component is backward compatible and interchangeable4 with other nonXL 3300 series 5 mm and 8 mm transducer system components5. This compatibility includes the 3300 5 mm probe, for applications in which an 8 mm probe is too large for the available mounting space.
The 330130-075-00-05 Bently Nevada 3300 XL Standard Extension Cable may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330130-075-00-05 3300 XL Standard Extension Cable Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-meter system also fully complies with the American Petroleum Institute’s (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability. All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components.
This cable is widely used in heavy industries (oil and gas, power generation, mining) for monitoring critical rotating equipment:
Radial Vibration Monitoring: Connects probes mounted on hydrodynamic bearings (e.g., turbines, compressors, and large motors) to a monitoring rack to detect shaft imbalance or misalignment.
Axial (Thrust) Position: Measures axial displacement of the shaft to prevent catastrophic contact between the rotor and stator.
Keyphasor® and Speed Sensing: Transmits timing pulses per revolution for speed measurement and phase analysis in diagnostic systems such as the Bently Nevada 3500.
Standard Industrial Environment: Unlike the "01" (armored) or "02" (connector protector) versions, the "-00" option indicates a standard unarmored cable. It is best suited for installation in protective conduits or cable trays where it is not susceptible to mechanical damage.
