- Prox/Seismic I/O Module with Internal Terminations for the documented Bently Nevada 3500 Machinery Protection System.
- Power consumption: 7.7 watts, typical.
- Standard I/O: 10 kΩ (Proximitor and acceleration inputs).
128229-01 belongs to the Bently Nevada 3500 Machinery Protection System and performs the documented prox/seismic i/o module with internal terminations role in the Bently Nevada 3500 machinery protection architecture. The retained technical evidence records Power consumption: 7.7 watts, typical; Standard I/O: 10 kΩ (Proximitor and acceleration inputs); Output Impedance: 550 Ω. The full marking, receiving hardware, connectors or terminals, configuration dependencies and installed position must be matched before substitution.
For installation, retain the Bently Nevada 3500 Machinery Protection System receiving position, connector or terminal arrangement and configuration record. After power restoration, review diagnostics and test the affected operating path before process release.
The 128229-01 Prox/Seismic I/O Module with Internal Terminations is supplied only after the complete hardware identity, condition and current OEM lifecycle status have been confirmed.
Bently Nevada 128229-01 Prox/Seismic I/O Module with Internal Terminations Manual(Datasheets), Link
Important Notice: The linked document or internal product-family information must identify the listed model or its documented family. Confirm the complete order code, hardware revision and installed-system requirements before replacement. Accessories, cables, software and certificates are included only when stated in the quotation. All prices are shown in USD.
Signal Mapping: 128229-01 performs the prox/seismic i/o module with internal terminations function within the Bently Nevada 3500 Machinery Protection System. The retained documentation identifies power consumption as 7.7 watts, typical; apply that value only to this documented execution.
Match the complete label, hardware form and functional position before transferring any setting, cable or termination from the removed unit.
Module Matching: approve 128229-01 only for the documented Bently Nevada 3500 machinery protection architecture. Compare rack, carrier or panel generation, connector keying, terminal numbering and all paired assemblies with the installation drawings.
Photograph both sides and the installed position before removal so revision markings, jumpers, addressing and channel allocation can be reconstructed accurately.
Function Review: isolate the equipment, remove stored energy and inspect the receiving hardware before installing 128229-01.
Restore power in the approved sequence, review status and diagnostics, then test every affected control, signal, relay, communication, protection or monitoring path against the commissioning record.
