- Safe 0-20 mA and 4-20 mA analog input FTA (16 channels)
- Field termination assembly module TSAI-1620m
- Enabling monitoring of the external power connected to the FTA module
The TSAI-1620m Field Terminal Module (FTA) serves as the interface between field components (such as sensors) in Safety Manager and the SAI-1620m Safety High-Density Analog Input Module. It can be used to connect signals from Class I Zone 2 hazardous locations.
The TSAI-1620m module features 16 analog input channels for both safety-related and non-safety-related applications. These 16 channels (divided into two groups of eight, sharing a single 0V power supply) are connected via a system interconnect cable (SICC-0001/Lx), which plugs into the SIC connector on the FTA module.
The FC-TSAI-1620M Honeywell Analog input FTA module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell FC-TSAI-1620M Analog input FTA module Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The FTA module features a universal snap-on mounting design, compatible with standard DIN and EN rails, and includes screw terminals for connecting power, grounding, and field wiring. The FS-TSGAS-1624 module contains 16 groups (16 channels). Each group has four screw terminals for optimal field wiring connections. Each channel has a grounding terminal for shielding analog input cables. Screw terminals are numbered 1 to 64.
Critical Process Monitoring:Connects to 4-20 mA transmitters to measure pressure, temperature, flow rate, or level in high-risk environments such as refineries and chemical plants.
Emergency Shutdown (ESD) Systems: Serves as an input point to sensors, triggering safety logic to shut down equipment when process deviations occur.
Boiler Management System (BMS): Monitors flame intensity and fuel pressure to ensure safe boiler and furnace operation.
High-Density Analog Inputs:Efficiently integrates 16 independent analog field signals into a single System Interconnect Cable (SICC) of the SAI-1620m input module.
