Features:
- Controller Chassis Module
- 19-inch standard rack mounting (Swing frame, fixed frame, or rear panel)
- TÜV Certified up to IEC 61508 SIL 3 safety standards
The inter-module bus (IMB) backplane is part of the chassis and provides the electrical interconnection and other services for the modules. The maximum data transfer rate of the IMB is 150Mbaud. There are no user-serviceable parts inside the chassis.
Modules are inserted by sliding them carefully into their slot position. Ensure that the Uchannels of the module top and bottom casings engage the raised guides of the upper and lower chassis plates. Ejector levers on the modules secure the modules within the chassis.
The T8100C ICS Triplex Controller Chassis Module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
ICS Triplex T8100C Controller Chassis Module manual(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The T8120C module is designed for high-integrity automation environments where any single point of failure could cause serious harm:
Emergency shutdown (ESD) systems, gas turbine and steam turbine control and protection cabinets, fire and gas (F&G) monitoring systems, and critical process controls in petrochemical plants, nuclear facilities, and oil and gas extraction.
The rear of the chassis is designed for direct connection of T8120/T812X processor interface adapters. These adapters snap into the backplane behind the processor socket, bringing out communication lines to enable Modbus master/slave functionality, network connectivity, and IRIG-B time synchronization without requiring changes to the front panel wiring.
