Features:
- ICS Triplex Input Smart Slot Jumper Cable
- 2.5-meter Input Smart Slot Jumper Cable
- 96-way LSZH wire harnesses shrouded in Megamide Sleeving
The Trusted TC000 Power Cable is specifically engineered to provide a reliable electrical interface between the Power Distribution Unit Miniature Circuit Breaker (MCB) T8292 and the Fan Assembly T8270 within a Trusted system architecture. This cable functions as a dedicated power transmission link, ensuring stable and uninterrupted delivery of supply voltage from the protection device (MCB) to the cooling subsystem. Its configuration supports controlled current flow while maintaining electrical isolation and operational safety within the cabinet infrastructure.
Designed for integration in high-availability and safety-critical control environments, the Trusted TC000 Power Cable incorporates robust insulation, secure termination interfaces, and precise connector compatibility with both T8292 and T8270 components. The cable assembly ensures minimal voltage drop, controlled thermal performance, and resistance to mechanical stress commonly encountered in control panels and industrial enclosures. Its construction supports consistent performance under continuous duty cycles, contributing to overall system reliability and thermal management efficiency.
The TC-306-02-2M5 ICS Triplex Input Smart Slot Jumper Cable may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
ICS Triplex TC-306-02-2M5 Input Smart Slot Jumper Cable Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
From a system engineering perspective, the Trusted TC000 Power Cable plays a vital role in sustaining the operational integrity of the cooling mechanism associated with the Trusted platform. By ensuring dependable power continuity from the T8292 MCB to the T8270 Fan Assembly, the cable supports effective heat dissipation, thereby safeguarding electronic modules from thermal overload conditions. Proper installation, routing discipline, and adherence to electrical load specifications are essential to maintaining optimal performance and long-term durability of the power distribution pathway.
- Intelligent Slot Redundancy
- The primary purpose of this cable is to provide hot-swappable redundancy for input modules. In an "intelligent slot" configuration, a spare module slot is used to back up multiple active modules within the same chassis.
- Module Connection: It physically interconnects the field interface of the active trusted digital or analog input module with the spare (backup) module slot.
- Continuous Monitoring: It allows the spare module to "see" field signals while the active module is still running. If the active module fails or requires maintenance, the system can switch to the spare module without interrupting the process or losing field data.
