Features:
- 3300 XL Extended Temperature Range Extension Cable
- 3300 XL 8 mm Proximity Transducer System
- The system provides an output voltage
The system provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.
Each 3300 XL 8 mm Transducer System component is backward compatible and interchangeable4 with other nonXL 3300 series 5 mm and 8 mm transducer system components5. This compatibility includes the 3300 5 mm probe, for applications in which an 8 mm probe is too large for the available mounting space.
The 330190-085-01-05 Bently Nevada 3300 XL Extended Temperature Range Extension Cable may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330190-085-01-05 3300 XL Extended Temperature Range Extension Cable Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-meter system also fully complies with the American Petroleum Institute’s (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability. All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components.
This cable is used in critical machinery protection systems where proximity probes must be installed in high-temperature areas, while Proximitor® sensors are installed in lower-temperature areas. Common applications include:
Gas turbines and steam turbines: Measuring vibration and location near high-temperature components of the machine.
High-temperature pumps: Monitoring axial thrust in chemical or refining processes.
Heavy-duty industrial gearboxes: Providing reliable signal transmission in harsh, abrasive environments.
