      Bently Nevada 3500/92 136180-01
      Bently Nevada 3500/92 136180-01
      Bently Nevada 3500/92 136180-01
      Bently Nevada 3500/92 136180-01
      Bently Nevada 3500/92 136180-01
      Bently Nevada 3500/92 136180-01
      · Product image is representative; revision or series may vary. Contact us to request a specific version.
      Get a Quote

      3500/92 136180-01

      Communication Gateway Module
      In Stock
      Ships by Tuesday, June 23
      Fast Shipping Available

      Product Information:

      The 3500/92 136180-01 is a communication gateway module motherboard manufactured by Bently Nevada. As the main processing card in the 3500 machine protection system, it transmits rack-mounted backplane data to the plant-wide process network, distributed control system (DCS), or programmable logic controller (PLC).

      Warranty Policy
      We provide 1 year warranty for all remaining parts.
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      Return Notice
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
      Shiping Mode
      Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
      Parts Availability
      Moore automated offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
      Expand All
      Collapse all

      Technical specifications for 3500/92 136180-01

      • Manufacturer:
        Bently Nevada
      • Product Category:
        TSI System
      • Spare Part Number:
        3500/92 （136180-01+136188-02）
      • Estimated shipping dimensions:
        24.1 x 2.44 x 24.2 cm
      • Weight:
        0.82 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Product Type:
        3500/92 Communication Gateway
      • Operating Temperature:
        -30°C to +65°C (-22°F to +149°F)
      • Storage Temperature:
        -40°C to +85°C (-40°F to +185°F)
      • Humidity:
        95%, non-condensing
      • Category Series:
        3500 Series Module
      • Communication Link:
        Ethernet, 10Mbps, and conforms to IEEE802.3
      • Protocol Ethernet:
        TCP/IP frame and Modbus/TCP
      • Connection:
        RJ-45 (telephone jack style) for 10BASE-T Ethernet cabling
      • Power Consumption:
        5.0 Watts typical with ModbusRS232/ RS422 I/O Module; 5.6 Watts typical with Modbus RS485 I/O Module
      • Stock:
        130
      Ask for Quote

      Alternative Names

      3500/92 136180-01 3500 92 136180 01 35OO/92 13618O-O1 3500/92 I36I80-0I 3500/92 136188-02 136188-02 125736-01 3500/92-01-01-00 133323-01 3500/92 133323-01 3500/92-04-01-00

      Information

      Overview Manuals Principle

      Features:

      • 3500/92 Communication Gateway Module
      • 3500/92 Communication Gateway
      • Supported protocols include Modicon Modbus protocol (via serial communications)
      The Bently Nevada™ 3500/92 Communication Gateway module provides extensive communication capabilities of all rack monitored values and statuses for integration with process control and other automation systems using both Ethernet TCP/IP and serial (RS232/RS422/RS485) communications capabilities. It also permits Ethernet communications with 3500 Rack Configuration Software and Data Acquisition Software.

      The 3500/92 supports the communication interfaces, communication protocols, and other features from the original 3500/90 with the exception of the primary value Modbus registers. The 3500/92 now has a Configurable Modbus Register Utility, which can provide the same functionality originally addressed by the primary value Modbus registers.

      The 3500/92 136180-01 Bently Nevada Communication Gateway Module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
      Bently Nevada 3500/92 136180-01 Communication Gateway Module Manuals(Datasheets), Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
      3500/92 Communication Gateway Module.The Ethernet connection to the 3500/92 is an RJ45 connection for 10BASE-T star configuration Ethernet networks.

      Manuals

      Technical notes

      Serving as a digital bridge connecting the 3500 mechanical protection system with the upper-level automation system, this is a full-height industrial-grade protocol conversion bus module. Through a high-frequency internal network, it continuously refreshes and collects real-time vibration, displacement, gap voltage, temperature, speed, alarms, and frame status data from all channels of the entire rack at an ultra-high frequency of less than one second.

      Ask our team:

      Related Products

      Browsing history

      FAQ

      View All Faqs
      • How does 3500/92 136180-01 facilitate seamless integration with plant-level control architectures?
        The 3500/92 136180-01 supports industry-standard communication protocols, allowing deterministic and non-deterministic data transfer to DCS, PLC, and SCADA platforms without compromising system performance or data fidelity.
      • What types of operational and diagnostic data are accessible through 3500/92 136180-01?
        The 3500/92 136180-01 provides structured access to real-time measurements, alarm states, system status indicators, and diagnostic information, enabling comprehensive visibility into machinery health and protection conditions.
      • In what way does 3500/92 136180-01 support both legacy and modern automation infrastructures?
        The 3500/92 136180-01 is engineered for interoperability, enabling coexistence with legacy control systems while simultaneously supporting modern digital architectures and networked condition monitoring solutions.
      • What is the significance of 3500/92 136180-01 for predictive maintenance and asset performance strategies?
        The 3500/92 136180-01 enables continuous data streaming to asset management and analytics platforms, forming a critical link between machinery protection data and predictive maintenance workflows.
      • What operational reliability features are embedded in 3500/92 136180-01?
        The 3500/92 136180-01 is designed for continuous-duty industrial operation, with robust hardware construction and deterministic communication behavior that align with the high-availability requirements of critical rotating equipment.
