The General Electric IC200ALG261 is a analog input module for GE VersaMax industrial automation applications. Documented product details include Analog input module utilized in the; Versamax series. It features eight; differential input channels and operates; across a voltage range of -10 to +10 Volts DC. Confirm the complete model code, hardware revision and supplied condition against the installed equipment before replacement.
Verify that the supplied item is marked IC200ALG261 and that its analog input module form, connectors and revision agree with the approved GE VersaMax receiving record.
For IC200ALG261, state the required condition, quantity, installed position, connected assemblies and document requirements in the written enquiry.
Apply only parameters supported by the exact IC200ALG261 record or a documented family source. Do not infer electrical ratings or interchangeability from appearance.
IC200ALG261 technical scope: Product Line: Versamax; Backplane Power Supply: 5 Volts DC; Input Range: -10 to +10 Volts DC (for both differential and common mode); Output Signal: 16-bit; Number of Channels: 8 differential input channels.
Use these values only for the listed hardware execution and verify the supplied label before installation.
Match IC200ALG261 to the approved GE VersaMax receiving position, connector or terminal arrangement and configuration record.
After power restoration, review diagnostics and test the affected analog input module path.
Obsolete/Discontinued by OEM
IC200ALG261 is a General Electric analog input module associated with the GE VersaMax platform. It interfaces the documented field signals with the control system through the assigned channels, terminals and installed I/O position. Correct selection depends on the complete model code, connector or terminal arrangement, hardware revision and receiving-system configuration. Before replacement, compare the original product label, installed slot or cabinet reference, connected assemblies and approved project records. After installation, review system diagnostics and function-test every affected channel, control path, protection function or communication link before returning the equipment to service.
