Features:
- Versatile box-style I/O carrier from the Versamax series
- This unit facilitates efficient connections and wiring with 36 IEC box-style terminals
- Allows for the integration of an I/O module, enabling effective system communication and control
The GE Fanuc IC200CHS022 is a box-type I/O carrier board whose main feature is its ability to optimize I/O connectivity in industrial automation environments. This device includes 36 IEC box-type terminals for easy wiring. It is compatible with I/O modules and provides the necessary installation support to enhance integration with existing automation systems.
The terminals can connect single or multi-strand wires, enabling flexible wiring configurations. Terminal wiring can accommodate one AWG #14-22 wire or up to two AWG #18 wires. This flexibility is crucial for various installation scenarios. The box-type carrier board can be easily mounted on DIN rails, simplifying the installation process for control panels or machinery.
The IC200CHS022 General Electric Compact I/O Carrier Board may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IC200CHS022 Compact I/O Carrier Board datasheet(manual), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The carrier board is designed to integrate up to four common terminals and power connection options to achieve the necessary electrical connections. For effective electromagnetic compatibility (EMC), DIN rail applications must be grounded. The carrier board supports communication via inter-carrier connectors, enhancing backplane communication and the field wiring capabilities of associated I/O modules. In summary, the IC200CHS022 is a key component designed to provide robust I/O connectivity for complex automation systems.
Field Wiring Termination: Provides 36 IEC box-type terminal blocks as connection points for field devices. Can handle up to 32 I/O points and 4 common power connections.
Space-Constrained Installation: Ideal for compact control cabinets with limited panel space due to its vertical mounting (perpendicular to the DIN rail).
Industrial Automation Nodes: Used to build "snap-on" compact I/O nodes for distributed control systems.
High Vibration Environments: While standard mounting is via a 35mm DIN rail, panel mounting is also available for applications requiring maximum resistance to mechanical shock and vibration.
