      Allen-Bradley 1756-OV32E
      Allen-Bradley 1756-OV32E

      • ISO 9001:2015 Certified

        Our quality management system covers sourcing,testing and dispatch

      • View Our Success Stories

        Real stories from real customer orders
      In Stock
      Ships by Monday, September 21
      Fast Shipping Available
      ControlLogix 32-Point DC Output Module

      1756-OV32E

      Spare Part Number

      PN1756-OV32E

      Product Information:

      Allen-Bradley 1756-OV32E is a ControlLogix 32-point electronically fused DC sinking output module.

      The module has two 16-point groups, operates from 10 to 30 V DC and supports up to 0.5 A per output at 50 °C with electronic short-circuit protection.

      Confirm the selected removable terminal block, group current, module derating and field-power wiring before commissioning the outputs.

      Product image is representative; revision or series may vary. Contact us to request a specific version.
      Get a Quote
      • One-year warranty
      • Global shipping
      • Exact-model verification
      WhatsApp: +86 180 2077 6792 Email parts team
      01


      Model Verified

      Model, revision and nameplate reviewed
      02


      Email confirmation

      You will get an email confirming that we have received your enquiry
      03


      Dedicated Account Manager

      One of our team will be in touch to confirm your part(s) specification and condition
      04


      Your quote

      You will receive a comprehensive quote tailored to your specific needs

      Technical specifications for

      1756-OV32E

      0 TECHNICAL PARAMETERS
      • Manufacturer:
        Allen-Bradley
      • Product Category:
        PLC Systems
      • Spare Part Number:
        1756-OV32E
      • Estimated shipping dimensions:
        17.5 x 14.5 x 3.6 cm
      • Weight:
        0.45 kg
      • Tariff Code:
        853890
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Outputs:
        32 electronically fused
      • Output grouping:
        2 groups of 16
      • Voltage category:
        12/24 V DC sinking
      • Operating voltage:
        10 to 30 V DC
      • Current per point:
        0.5 A at 50 °C; 0.35 A at 60 °C
      • Current per group:
        8 A at 50 °C
      • Current per module:
        16 A at 50 °C
      • Backplane power:
        2.04 W
      • Power dissipation:
        Maximum 5.88 W at 60 °C
      • Compatible RTB:
        1756-TBCH or 1756-TBS6H
      • Operating temperature:
        0 to 60 °C
      • Stock Availability:
        52
      Ask for Quote
      WHAT HAPPENS NEXT?

      From enquiry to delivery

      Six clear steps show what information is required and what the written quotation will contain.
      • 01

        Find the product

        Search the part number or send an inquiry for obsolete, discontinued or hard-to-find parts.
      • 02

        Provide the details

        Share the exact part number, quantity, condition, revision, destination and any required certificates or photos.
      • 03

        Review the quotation

        Receive price, currency, condition, availability, warranty, lead time, shipping terms and quotation validity in writing.
      • 04

        Confirm the order

        Accept the quotation in writing and complete the required payment before shipment.
      • 05

        Pay by bank transfer

        Pay the full invoiced amount by bank wire in RMB/CNY, GBP, EUR or USD using the official invoice details.
      • 06

        Verify and dispatch

        The item receives a pre-shipment inspection and suitable protective packaging. Functional testing is performed only where appropriate equipment and procedures are available for the specific item. We confirm the applicable inspection scope and provide tracking after dispatch.
      Request a Verified Quote
      BUYER INFORMATION

      Product condition level information

      Commercial details are confirmed in writing before payment.
      • 01

        Factory Sealed

        Unused product with the original factory seal intact; packaging age or storage marks may still be present.

        view
      • 02

        Original Pack

        Unused product in original manufacturer packaging that was not originally factory sealed.

        view
      • 03

        Factory New

        New and current product sourced through the manufacturer or authorized supply channel when expressly confirmed in the quotation.

        view

      Revisions

      Revision Part #

      Also known as

      1756-OV32E/A
      1756-OV32E Ser A, Series A, Rev A
      Get Parts Quote

      Alternative Names

      1756-OV32E 1756-OV32EK 1756-TBCH

      Information

      Overview Manuals Technical Specifications Configuration Notes Application Guidance

      Features:

      • Output points: 32
      • Voltage range: 10 to 30 VDC
      • Output type: Sinking, electronically fused
      • Current: 1 A per point
      • Connector: 36-pin RTB

      Allen-Bradley 1756-OV32E is a ControlLogix 32-Point DC Output Module in the ControlLogix 1756 I/O family. It controls 24 VDC actuators, indicators, solenoids and other sinking-output loads in ControlLogix systems.

      Use with a compatible 1756 chassis, controller, 36-pin removable terminal block and calculated field-load current.

      The Allen-Bradley 1756-OV32E may be supplied and supported by Moore Automated according to the stated manufacturer lifecycle and confirmed stock condition.
      Allen-Bradley 1756-OV32E ControlLogix 32-Point DC Output Module Manuals(Datasheets), Link Important Notice: Other accessories, manuals, cables, calibration data, software, licenses and related items are not included with this equipment unless listed in the stock item description. All prices are shown in USD.

      Technical Specifications:

      • Output points: 32
      • Voltage range: 10 to 30 VDC
      • Output type: Sinking, electronically fused
      • Current: 1 A per point

      It controls 24 VDC actuators, indicators, solenoids and other sinking-output loads in ControlLogix systems.

      Configuration Notes:

      • Voltage range: 10 to 30 VDC
      • Output type: Sinking, electronically fused
      • Current: 1 A per point
      • Connector: 36-pin RTB

      Use with a compatible 1756 chassis, controller, 36-pin removable terminal block and calculated field-load current.

      Application Guidance:

      • Output type: Sinking, electronically fused
      • Current: 1 A per point
      • Connector: 36-pin RTB

      requires correct sinking-load wiring, group supply protection, RTB selection, keying and module configuration.

      Technical notes

      Allen-Bradley 1756-OV32E is a ControlLogix 32-Point DC Output Module in the ControlLogix 1756 family. The module has two 16-point groups, operates from 10 to 30 V DC and supports up to 0.5 A per output at 50 °C with electronic short-circuit protection. Confirm the complete catalog number, compatible system hardware, wiring, environmental limits and lifecycle status against the manufacturer documentation before installation.
      PRODUCT & ORDER FAQS

      Questions buyers ask about 1756-OV32E

      • How can I identify 1756-OV32E?

        Verify the complete catalog number 1756-OV32E on the product label and compare the documented 32 electronically fused sinking outputs before installation.

      • What is 1756-OV32E compatible with?

        It installs in a ControlLogix 1756 chassis and uses an approved 36-pin removable terminal block such as 1756-TBCH or 1756-TBS6H.

      • Where is 1756-OV32E typically used?

        It provides protected 10 to 30 V DC sinking outputs for industrial actuators and control loads.

      • What should be checked before installation?

        Confirm the mounting, wiring, supply, environmental limits and system firmware stated in the official documentation for 1756-OV32E.

      • Is 1756-OV32E available from stock?

        Stock is confirmed at the time of quotation. Moore Automated can check the exact 1756-OV32E revision and configuration before shipment.

      • What warranty is provided?

        Warranty terms are confirmed with the quotation and apply to the supplied 1756-OV32E hardware after inspection and functional verification.

      • How is 1756-OV32E shipped?

        The unit is securely packed and dispatched from Xiamen, Fujian, China, with fast shipment available and an estimated processing time of 3 days.
