      Bently Nevada 330102-00-16-10-02-05
      Bently Nevada 330102-00-16-10-02-05
      · Product image is representative; revision or series may vary. Contact us to request a specific version.
      Get a Quote

      330102-00-16-10-02-05

      3300 XL 8 mm Proximity Probes
      In Stock
      Ships by Tuesday, June 23
      Fast Shipping Available

      Product Information:

      Part number 330102-00-16-10-02-05 represents the Bently Nevada 3300 XL 8 mm proximity probe, featuring an integrated stainless steel armored housing. This 8 mm eddy current sensor is a globally leading product for monitoring critical parameters of rotating machinery, particularly suitable for monitoring radial vibration, axial (thrust) shaft position, and machine speed/timing (critical phase). Furthermore, the flexible armored conduit protects the internal coaxial cable from damage caused by compression, clamping, sharp metal edges, and hot oil splashes within the machine housing.


      Warranty Policy
      We provide 1 year warranty for all remaining parts.
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      Return Notice
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
      Shiping Mode
      Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
      Parts Availability
      Moore automated offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
      Expand All
      Collapse all

      Technical specifications for 330102-00-16-10-02-05

      • Manufacturer:
        Bently Nevada
      • Product Category:
        TSI System
      • Estimated shipping dimensions:
        135 x 1.5 x 1.2 cm
      • Weight:
        0.11 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Unthreaded Length:
        0.0 in
      • Overall Case Length:
        1.6 in
      • Total Length:
        1.0 meter (3.3 feet)
      • Connector and Cable-Type:
        Miniature coaxial ClickLoc connector, standard cable
      • Agency Approval:
        CSA, ATEX, IECEx Approvals
      • Probe Tip Material:
        Polyphenylene sulfide (PPS)
      • Probe Case Material:
        AISI 303 or 304 stainless steel (SST)
      • Operating and Storage Temperature:
        -52°C to +177°C (-62°F to +350°F)
      • Probe Relative Humidity:
        Less than a 3% change
      • Product Type:
        Proximity Probes
      • Category Series:
        3300 XL Series
      • Stock:
        50
      Ask for Quote

      Alternative Names

      330102 00 16 10 02 05 330I02-00-I6-I0-02-05 3301O2-OO-16-1O-O2-O5 330102-00-16-10-02-00 330102-00-16-10-02-CN 330102-00-16-10-02-BR 330102-00-16-10-02-RU 330102-00-16-10-01-05 330102-00-16-10-11-05 330102-00-16-10-12-05 330102-00-16-10-12-00 330102-00-16-10-11-CN 330102-00-16-15-11-00

      Information

      Overview Manuals Basic Info Ordering Info Calibration Requirements

      Features:

      • 3300 XL 8 mm Proximity Probes
      • 3300 XL 8 mm Proximity Transducer System
      • 330102 3300 XL 8 mm Probe, 3/8-24 UNF thread, with armor
      The 3300 XL probe and extension cable also reflect improvements over previous designs. A patented TipLoc molding method provides a more robust bond between the probe tip and the probe body. The probe’s cable incorporates a patented CableLoc design that provides 330 N (75 lbf) pull strength to more securely attach the probe cable and probe tip.

      8 mm probes provide a thicker encapsulation of the probe coil in the molded PPS plastic probe tip. This results in a more rugged probe. The larger diameter of the probe body also provides a stronger, more robust case. We recommend that you use 8 mm probes when possible to provide optimal robustness against physical abuse.

      The 330102-00-16-10-02-05 Bently Nevada 3300 XL 8 mm Proximity Probes may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
      Bently Nevada 330102-00-16-10-02-05 3300 XL 8 mm Proximity Probes Manuals(Datasheets), Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
      • Model: 330102-00-16-10-02-05
      • Warranty: One-year warranty
      • Condition: Brand new, original, in stock
      • Product Family: 3300 XL 8 mm Proximity Transducer System
      3300 XL 8 mm Proximity Probes:
      330102 3300 XL 8 mm Probe, 3/8-24 UNF thread, with armor
      330102-Axx-Bxx-Cxx-Dxx-Exx

      A: Unthreaded Length
      Order in increments of 0.1 in.
      Length configurations:
      Maximum unthreaded length: 8.8 in.
      Minimum unthreaded length: 0.0 in.
      Example: 0 4 = 0.4 in.

      B: Overall Case Length
      Order in increments of 0.1 in.
      Standard thread configurations:
      Maximum case length: 9.6 in.
      Minimum case length: 0.8 in.
      Example: 2 4 = 2.4 in.

      C: Total Length
      05: 0.5 meter (1.6 feet)
      10: 1.0 meter (3.3 feet)
      15: 1.5 meter (4.9 feet)
      20: 2.0 meters (6.6 feet)
      30: 3.0 meters (9.8 feet)
      50: 5.0 meters (16.4 feet)
      90: 9.0 meters (29.5 feet)

      D: Connector and Cable-Type
      01: Miniature coaxial ClickLoc connector with connector protector, standard cable
      02 Miniature coaxial ClickLoc connector, standard cable
      11: Miniature coaxial ClickLoc connector with connector protector, FluidLoc cable
      12: Miniature coaxial ClickLoc connector, FluidLoc cable

      E: Agency Approval Option
      00: Not required
      05: CSA, ATEX, IECEx Approvals
      Because this probe uses a 1.0-meter integrated lead, it cannot be directly connected to a Proximitor sensor. The included extension cable must be used to build a compliant circuit: to build a standard 5.0-meter total length system, use this probe with a 4.0-meter extension cable; to build a standard 9.0-meter total length system, use this probe with an 8.0-meter extension cable.

      Manuals

      Technical notes

      The Bently Nevada 330102-00-16-10-02-05 is a 3300 XL 8mm eddy current probe designed specifically for fluid diaphragm bearings. It features a 3/8-24 UNF threaded interface, a self-reversing lock nut, a 1.6-inch (approximately 4 cm) long housing, and a 1.0-meter (approximately 2-meter) long cable. This sensor provides high-precision, non-contact monitoring with a depth of 2mm over a temperature range of -51°C to +177°C and is CSA, ATEX, and IECEx explosion-proof certified.

      Ask our team:

      Related Products

      Browsing history

      FAQ

      View All Faqs
      • How does the Bently Nevada 330102-00-16-10-02-05 optimize non-contact shaft displacement measurement through its precisely designed eddy current sensing architecture?
        The 330102-00-16-10-02-05 is designed to provide high-precision radial vibration and shaft position measurements, enabling reliable mechanical condition assessment of critical rotating equipment.
      • Why is the Bently Nevada 330102-00-16-10-02-05 frequently used in API 670-compliant turbomachinery protection systems that require superior measurement linearity?
        The 330102-00-16-10-02-05 provides stable and repeatable displacement signals, supporting mechanical protection, fault diagnosis, and predictive maintenance.
      • What metrological advantages does the Bently Nevada 330102-00-16-10-02-05 offer through its calibrated probe configuration and system-matched sensor design?
        The 330102-00-16-10-02-05 ensures consistent measurement accuracy, minimizes signal drift, and provides reliable long-term operational performance.
      • How does the Bently Nevada 330102-00-16-10-02-05 facilitate advanced rotor dynamics modeling, trajectory visualization, and phase vector analysis?
        The 330102-00-16-10-02-05 provides high-resolution displacement signals, supporting comprehensive vibration diagnostics and mechanical performance optimization.
      • Why is the Bently Nevada 330102-00-16-10-02-05 an integral part of a predictive maintenance ecosystem focused on the reliability of rotating equipment?
        The 330102-00-16-10-02-05 continuously provides accurate vibration data, helping maintenance teams identify and address mechanical problems before they escalate.
