Features:
- 3300 5mm Proximity Probes
- 3300 5mm Probe, M8 x 1 thread,without armor
- 3300 5 mm Transducer System
The 3300 5 mm probe improves upon previous designs. A patented TipLoc molding method provides a more robust bond between the probe tip and the probe body. The 3300 5 mm system is orderable with Fluidloc cable options for preventing oil and other liquids from leaking out of the machine through the cable’s interior.
The 3300 5 mm probe and 3300 XL extension cable have corrosion-resistant, gold-plated brass ClickLoc connectors. These connectors require only finger-tight torque (connectors will "click"), and the specially engineered locking mechanism prevents the connectors from loosening. The connectors require no special tools for installation or removal.
The 330173-03-08-05-02-05 Bently Nevada 3300 5mm Proximity Probes may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330173-03-08-05-02-05 3300 5mm Proximity Probes Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Model: 330173-03-08-05-02-05
- Warranty: One-year warranty
- Condition: Brand new, original, in stock
- Product Family: 3300 5 mm Transducer System
3300 5mm Proximity Probes
330173 3300 5mm Probe, M8 x 1 thread, without armor
330173-AA-BB-CC-DD-EE
A: Unthreaded Length
Length configurations:
Maximum unthreaded length: 2 3 = 230mm
Minimum unthreaded length: 0 0 = 0.0mm
B: Overall Case Length
Order in increments of 10mm
Metric thread configurations:
Maximum unthreaded length: 2 5 = 250mm
Minimum unthreaded length: 0 2 = 20mm
C: Total Length
0 5: 0.5 meter (1.6 feet)
1 0: 1.0 metre (3.3 feet)
2 0: 2.0 metres (6.6 feet)
5 0: 5.0 metres (16.4 feet)
9 0: 9.0 metres (29.5 feet)
D: Connector
0 1: Miniature coaxial ClickLoc connector with connector protector, standard cable
0 2: Miniature coaxial ClickLoc connector, standard cable
1 1: Miniature coaxial ClickLoc connector with connector protector, FluidLoc cable
1 2: Miniature coaxial ClickLoc connector, FluidLoc cable
E: Agency Approval
0 0: Agency Approval Option
0 5: Multiple Approvals
1.Compact 5mm Tip: Optimized design for easy insertion into small-diameter countersunk holes or extremely narrow target areas, while fully compatible with matching system extension cables.
2.Coaxial Connector: Equipped with a gold-plated thumbscrew locking mechanism that makes a "click" sound when locked, preventing the field connection from loosening under mechanical vibration.
3.TiptLoc Molding Process: Utilizes a patented manufacturing process to create a strong and durable connection between the polyphenylene sulfide (PPS) probe tip and the AISI 303/304 stainless steel housing.
