330190-XXX-00-05 173679-13 is a Bently Nevada 3300 XL Extended Temperature Range Extension Cable for the 3300 system. It connects the probe to a compatible Proximitor Sensor. Key specifications: Cable Length: XXX Length; Cable: Standard cable. Match the full order code and hardware before replacement.
The Bentley Nevada 330190-XXX-00-05 (modified 173679-13) is a wide-temperature range extension cable (ETR) designed specifically for the 3300 XL 8 mm system, maintaining a high stable sensitivity output of 200 mV/mil under extreme temperatures. This product features a standard coaxial construction with a ClickLoc connector and supports multiple explosion-proof certifications, making it suitable for harsh industrial rotating machinery environments.
The exact 330190-XXX-00-05 173679-13 execution must be confirmed by its complete order code, condition, connected 3300 system and included scope before purchase or replacement.
Bently Nevada 330190-XXX-00-05 173679-13 3300 XL Extended Temperature Range Extension Cable manual (Datasheet), Link
Important Notice: Confirm the complete order code, hardware execution and connected system before replacement. Accessories, cables, calibration data, software and certificates are included only when stated in the written quotation.
Review 330190-XXX-00-05 173679-13 by complete length and construction code. Retained facts: Cable Length: XXX Length; Cable: Standard cable; Agency Approval: CSA, ATEX, IECEx Approvals. Do not change the calibrated total system length when replacing an extension or integral lead.
Match every connector, protector, armor or FluidLoc option and the receiving probe/Proximitor Sensor. Route the cable without sharp bends, crushing, connector side-load or contamination.
Inspect continuity and insulation where applicable, seat the connectors, compare channel bias with the recorded value and confirm stable vibration or position response before release.
