- 3300 XL 8 mm Proximity Transducer System
- 330192 3300 XL 8 mm ETR Probe, 3/8-24 UNF thread, with armor
- 3300 XL 8 mm Extended Temperature Range (ETR) Proximity Probes
The system provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.
Each 3300 XL 8 mm Transducer System component is backward compatible and interchangeable4 with other nonXL 3300 series 5 mm and 8 mm transducer system components. This compatibility includes the 3300 5 mm probe, for applications in which an 8 mm probe is too large for the available mounting space.
The 330192-00-20-10-00 Bently Nevada 3300 XL 8 mm Extended Temperature Range (ETR) Proximity Probes may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330192-00-20-10-00 3300 XL 8 mm Extended Temperature Range (ETR) Proximity Probes Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 3300 XL 8 mm system is our most advanced eddy current proximity sensor system. The standard 3300 XL 8 mm 5-meter system fully complies with American Petroleum Institute (API) 670 standards, meeting requirements in terms of mechanical construction, linear range, accuracy, and temperature stability. All 3300 XL 8 mm proximity sensor systems achieve this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need for individual component matching or bench calibration.
- Hydrodynamic Bearing Monitoring: Used to measure radial vibration and axial (thrust) position in critical rotating equipment such as steam turbines, compressors, and pumps.
- Key Phasor and Velocity Signals: Provides accurate phase reference timing signals and measures rotational speed for overspeed protection systems.
- Demanding Industrial Racks: Typically used in areas requiring cable abrasion or crush protection, as this particular model includes integrated stainless steel armor.
