Features:
- 3300 NSv Reverse Mount Probe
- 330906-02-12 3/8-24 UNF threads
- 3300 XL NSv Proximity Transducer System
The 3300 XL NSv Proximity Transducer system is intended for use with centrifugal air compressors, refrigeration compressors, process gas compressors, and other machines with tight installation requirements.
The primary uses for the 3300 XL NSv Transducer System are for areas where counter bore, sideview, or rearview restrictions limit the use of standard Bently Nevada 3300 and 3300 XL 5 and 8 mm Transducer Systems. It is also ideal for small target applications, such as measuring radial vibration on shafts smaller than 51 mm (2 in) or axial position on flat targets smaller than 15 mm (0.6 in).
The 330906-02-12-10-12-05 Bently Nevada 3300 NSv Reverse Mount Probe may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330906-02-12-10-12-05 3300 NSv Reverse Mount Probe Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 3300 XL NSv sensor system has an average scale factor of 7.87 V/mm (200 mV/mil), which is the most commonly used output value for eddy current sensors. Its enhanced side-view and small-target characteristics result in a shorter linear range than the Bently Nevada 3300 XL series 5 mm and 8 mm sensor systems. Its 1.5 mm (60 mil) linear range surpasses that of the 3000 series 190 sensor system.
- Small Shaft Vibration: Optimized for measuring radial vibration of shafts as small as 30 mm (1.2 inches) in diameter.
- Compact Compressors: Commonly used in centrifugal air compressors, refrigeration compressors, and small process gas compressors.
- Limited Side-View Area: Ideal for installation in areas with small countersunk holes or limited clearance, avoiding interference with sensor signals from standard 5 mm or 8 mm probes.
- Hydrodynamic Bearing Machinery: Used for monitoring axial (thrust) position, radial vibration, and velocity reference (Keyphasor®) of critical rotating machinery.
- Harsh Environments: Utilizes FluidLoc™ cables, making it suitable for applications where machine oil or other liquids may seep into the cable.
