Features:
- Module of GE Fanuc series 90-30 PLC systems
- Series 90-30 I/O Expansion Baseplate Module
- This module is a 5-slot expansion baseplate from the Series 90-30 Programmable Logic Controller (PLC) platform.
Its key features include five (5) I/O slots, one (1) power supply slot, and one (1) expansion port. It supports standard 90-30 series I/O modules and dedicated modules. It can be directly mounted to the control panel using the included mounting clips. It works with the CPU backplane and connects via the CPU backplane's expansion port.
Using the IC693CHS398 allows the CPU module to control a greater number of I/O modules. The number of expansion backplanes (e.g., IC693CHS398) allowed per system depends on the CPU model used. CPUs 331, 340, and 341 can have up to four expansion backplanes installed simultaneously; CPUs 350 and later can have up to seven.
The IC693CHS398 GENERAL ELECTRIC 5-slot expansion baseplate module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
GENERAL ELECTRIC IC693CHS398 5-slot expansion baseplate module datasheet(manual), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The IC693CHS398 has five I/O slots, which are also compatible with option modules. These slots are specially sized to prevent incorrect module installation. The backplane requires a dedicated power supply module to operate. The power supply module is installed in a dedicated power supply slot on the left side of the hardware. There is also an expansion backplane port on the far right of the hardware for connecting additional expansion backplanes.
The IC693CHS398 is designed for a variety of industrial solutions requiring high-speed logic and distributed monitoring.
1. Manufacturing and Assembly: Used for high-speed packaging, material handling, and injection molding to control automated machinery and safety interlocks.
2. Water and Utility Management: Used in water treatment plants and continuous discharge monitoring systems.
3. Energy Management: Integrated into energy networks for real-time monitoring and data acquisition of distributed assets.
4. Process Control: Supports batch processing and temperature/flow measurement in the chemical, food processing, and pharmaceutical industries.
Revision Part #
Also known as
IC693CHS398B
IC693CHS398-B, Series B, Rev B
IC693CHS398C
IC693CHS398-C, Series C, Rev C
IC693CHS398CAJ
IC693CHS398-CAJ, Series CAJ, Rev CAJ
IC693CHS398E
IC693CHS398-E, Series E, Rev E
IC693CHS398F
IC693CHS398-F, Series F, Rev F
