Features:
- Module of GE Fanuc series 90-30 PLC systems
- Series 90-30 Combination I/O module
- That is part of the Series 90-30 Programmable Logic Controller (PAC) series
The IC693MDR390 is a 90-30 Series Programmable Logic Controller (PLC) platform component module that integrates discrete input and output modules. This module features eight (8) discrete input channels that accept input signal voltages from -30 to +30 VDC, with a rated voltage of 24 VDC and a typical input current of 7.5 mA at the rated voltage. It also features eight (8) discrete output channels in the form of normally open (N.O.) relay contacts, operating at voltages from 5 to 30 VDC or 5 to 250 VAC at frequencies of 50/60 Hz.
The IC693MDR390 is a single-slot module that can be installed in any I/O slot on a 90-30 Series baseboard. It is compatible with any central processing unit (CPU) module, such as embedded CPUs and modular CPUs. This module can be installed on the local I/O backplane where the CPU resides, or on an expansion or remote I/O backplane. The IC693MDR390's input channels have an on-state voltage of 15-32VDC and an on-state current of 4mA; the off-state voltage range is 0-5VDC, and the off-state current is 1.5mA.
The IC693MDR390 GENERAL ELECTRIC Combination I/O module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
GENERAL ELECTRIC IC693MDR390 Combination I/O module datasheet(manual), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The typical response time (signal on and off transition) for the input channels is 7ms. Conversely, the typical response time (signal on and off transition) for the output channels is 15ms. The module's backplane current consumption is 80mA when all I/Os are active and 70mA when all outputs are active.
1. Machine Control Interface: Manages simple machine start/stop sequences and safety interlocks.
2. Material Handling: Controls conveyor system drives and monitors limit switches to ensure accurate packaging positioning.
3. HVAC Control: Controls fans, dampers, and heaters via relays based on feedback from thermostats or pressure switches.
4. Food and Beverage Processing: Provides basic timing and on/off control for packaging equipment or labeling machines.
5. Simple Automation: Suitable for vending machines, dispensing systems, and low-end industrial labeling applications.
Revision Part #
Also known as
IC693MDR390B
IC693MDR390-B, Series B, Rev B
IC693MDR390C
IC693MDR390-C, Series C, Rev C
IC693MDR390D
IC693MDR390-D, Series D, Rev D
