Certified HIMatrix F2 DO 16 02
Key Maintenance & Overcurrent
Features:
- 2 safety relays with forcibly guided contacts,1 standard relay
- 16 potential-free normally open contacts
- Relies on the proprietary SafeEthernet protocol over standard Ethernet cabling to maintain a deterministic, safety-jacketed data link back to the main CPU rack
The HIMA F2DO1602 operates on a standard 24VDC voltage, with a power consumption range of 18W to 74W (depending on the output load). Its typical response time is less than 10 milliseconds, ensuring accurate and timely response even in hazardous environments. In terms of field deployment and environmental adaptability, the F2DO1602 module is designed for harsh field environments, supporting field installation in Zone 2 explosion-proof hazardous areas.
When used with a cabinet compliant with EN 60079-15 and with a protection rating of at least IP54, the module can operate stably over a wide temperature range of -20°C to +60°C and can function in dusty environments. This distributed solution places valves and actuators directly near the industrial site, significantly reducing the cost of traditional long-distance copper cabling from the control room to the industrial site and completely eliminating the safety hazards associated with intermediate transmission links.
The F2DO1602 HIMA Safety-Related Controller Output Module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
HIMA F2DO1602 Safety-Related Controller Output Module MANUAL(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
1.CE: EMC, ATEX Zone 2
2.TÜV:
IEC 61508 1-7:2000 up to SIL 3
IEC 61511:2004
EN 954-1:1996 up to Cat. 4
3.TÜV ATEX:
94/9/EG
EN 1127-1
EN 61508
4.UL Underwriters Laboratories Inc.:
ANSI/UL 508, NFPA 70 – Industrial Control Equipment
CSA C22.2 No.142
UL 1998 Software Programmable Components
NFPA 79 Electrical Standard for Industrial Machinery
IEC 61508
5.FM Approvals:
Class I, DIV 2, Groups A, B, C and D
Class 3600, 1998
Class 3611, 1999
Class 3810, 1989
Including Supplement #1, 1995
CSA C22.2 No 142
CSA C22.2 No 213
When integrating the F2DO1602 into an emergency stop (ESD) circuit, protecting the internal relays from induced back EMF spikes is crucial:
External fuse: HIMA guidelines require the installation of an external time-delay fuse of up to 10 A on the power line to prevent overcurrent from blowing the contacts.
Relay lifecycle tracking: Because these are physical mechanical relays, their lifespan depends on the switching cycle. Engineers should periodically obtain the runtime diagnostic counter via SILworX to schedule preventative module replacement before contact performance deteriorates.
