Overview
Manuals
Location of Control Processor modules
System Architecture & Placement
Features:
- Chassis for redundant or non-redundant Controller (Safety Manager)
- The Controller chassis CPCHAS-0001 is used to contain the Control Processor modules
- The Controller chassis is generally located at the top position in the cabinet, and the IO chassis at lower positions
The Controller chassis CPCHAS-0001 is used to contain the Control Processor modules. Each Safety Manager has one Controller chassis. The Controller chassis is generally located at the top position in the cabinet, and the IO chassis at lower positions.
The Controller housing has been designed specifically for Safety Manager. It is a 19" housing that is open at the front and covered at the back. Control Processor modules are placed in the chassis through the front of the housing with the use of module guides, which are located at the bottom and top plate of the housing. The modules are locked in the chassis with the quarter turn fasteners, located below the module-grips.
The FC-CPCHAS-0001 Honeywell Controller chassis module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell FC-CPCHAS-0001 Controller chassis module Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The Controller chassis CPCHAS-0001 contains all Control Processor modules. The below table shows the location of the Control Processor modules in a non-redundant and a redundant Controller (as seen from the front of the cabinet). As you can see, all Control Processor modules are doubled in a redundant Controller configuration, with the exception of the Battery and Key switch module, which is shared by both Control Processors
Centralized Positioning: Each security manager configuration includes a controller chassis, typically bolted to the highest point inside the rack to maximize thermal efficiency and simplify communication with the I/O chassis below.
Configurable Backplane Topology: The integrated CPB-0001 backplane architecture supports slots for standalone (non-redundant) or fully synchronous, dual-fault-tolerant (redundant) processor system layouts.
Secure Locking Rails: Built-in structural slots on the top and bottom plates utilize quarter-turn front fasteners to prevent modules from detaching due to loose connections or vibration.
