      Bently Nevada 330104-06-14-10-02-00
      Bently Nevada 330104-06-14-10-02-00
      Bently Nevada 330104-06-14-10-02-00
      Bently Nevada 330104-06-14-10-02-00
      Bently Nevada 330104-06-14-10-02-00
      Bently Nevada 330104-06-14-10-02-00

      • ISO 9001:2015 Certified

        Our quality management system covers sourcing,testing and dispatch

      • View Our Success Stories

        Real stories from real customer orders
      In Stock
      Ships by Monday, September 21
      Fast Shipping Available
      3300 XL 8 mm long-body M10×1 armored proximity probe

      330104-06-14-10-02-00

      Spare Part Number

      PN330104-06-14-10-02-05, 330104-06-14-10-02-CN

      Product Information:

      The Bently Nevada 330104-06-14-10-02-00 is an armored M10×1 3300 XL 8 mm proximity probe with a 60 mm unthreaded section, 140 mm case, and 1.0 m total length. It uses a miniature ClickLoc connector and forms part of a matched proximity-measurement chain. Verify the full ordering code, cable length, Proximitor Sensor, and mounting clearance before replacement.


      Product image is representative; revision or series may vary. Contact us to request a specific version.
      Get a Quote
      • One-year warranty
      • Global shipping
      • Exact-model verification
      WhatsApp: +86 180 2077 6792 Email parts team
      01


      Model Verified

      Model, revision and nameplate reviewed
      02


      Email confirmation

      You will get an email confirming that we have received your enquiry
      03


      Dedicated Account Manager

      One of our team will be in touch to confirm your part(s) specification and condition
      04


      Your quote

      You will receive a comprehensive quote tailored to your specific needs
        • PRODUCT OVERVIEW

          What is this product?

          Bently Nevada 330104-06-14-10-02-00 is an armored 3300 XL 8 mm proximity probe for non-contact shaft displacement and vibration measurements. Its extended M10×1 geometry combines a 60 mm unthreaded section, 140 mm case, 1.0 m total length and a miniature ClickLoc connector.

          Source boundary

          Exact-model hardware values shown here are qualified from public technical cross-references and require order-stage confirmation.
        • APPLICATIONS

          Where it may be used

          Applications describe the product family and are not an automatic compatibility or functional-safety approval.

          Vibration channels

          Machinery radial-vibration channels.

          Position channels

          Axial-position monitoring points.

          Displacement sensing

          Shaft displacement measurements.

          Protection systems

          API 670 protection-system installations.
      Technical specifications for

      330104-06-14-10-02-00

      0 TECHNICAL PARAMETERS
      • Manufacturer:
        Bently Nevada
      • Product Category:
        Sensor
      • Spare Part Number:
        330104-06-14-10-02-05, 330104-06-14-10-02-CN
      • Estimated shipping dimensions:
        114 x 1.5 x 1.5 cm
      • Weight:
        0.2 kg
      • Tariff Code:
        9031809090
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Transducer system:
        3300 XL 8 mm
      • Probe type:
        330104 M10×1 with armor
      • Unthreaded length option:
        06 — 60 mm
      • Overall case length option:
        14 — 140 mm
      • Total length option:
        10 — 1.0 m
      • Connector option:
        02 — miniature ClickLoc coaxial
      • Agency approval option:
        00 — not required
      • Probe tip diameter:
        8 mm
      • Nominal scale factor:
        7.87 V/mm (200 mV/mil)
      • Frequency response:
        0 Hz to 10 kHz
      • Minimum target size:
        15.2 mm diameter
      • Minimum shaft diameter:
        50.8 mm
      • System standard:
        API 670 compliant configuration
      • Stock Availability:
        45
      Ask for Quote
      WHAT HAPPENS NEXT?

      From enquiry to delivery

      Six clear steps show what information is required and what the written quotation will contain.
      • 01

        Find the product

        Search the part number or send an inquiry for obsolete, discontinued or hard-to-find parts.
      • 02

        Provide the details

        Share the exact part number, quantity, condition, revision, destination and any required certificates or photos.
      • 03

        Review the quotation

        Receive price, currency, condition, availability, warranty, lead time, shipping terms and quotation validity in writing.
      • 04

        Confirm the order

        Accept the quotation in writing and complete the required payment before shipment.
      • 05

        Pay by bank transfer

        Pay the full invoiced amount by bank wire in RMB/CNY, GBP, EUR or USD using the official invoice details.
      • 06

        Verify and dispatch

        The item receives a pre-shipment inspection and suitable protective packaging. Functional testing is performed only where appropriate equipment and procedures are available for the specific item. We confirm the applicable inspection scope and provide tracking after dispatch.
      Request a Verified Quote
      BUYER INFORMATION

      Product condition level information

      Commercial details are confirmed in writing before payment.
      • 01

        Factory Sealed

        Unused product with the original factory seal intact; packaging age or storage marks may still be present.

        view
      • 02

        Original Pack

        Unused product in original manufacturer packaging that was not originally factory sealed.

        view
      • 03

        Factory New

        New and current product sourced through the manufacturer or authorized supply channel when expressly confirmed in the quotation.

        view

      Alternative Names

      330104-06-14-10-02-05 330104 06 14 10 02 00 3301040614100200 330104-06-14-10-02-CN

      Information

      Overview Manuals Technical Specifications Probe Configuration Application Guidance

      Features:

      • Product family: 3300 XL 8 mm Proximity Transducer System
      • Probe type: 330104 8 mm proximity probe
      • Mounting thread: M10 x 1
      • Cable armor: Armor included
      • Unthreaded length: 0.6 in (15.2 mm)
      • Case length: 1.4 in (35.6 mm)
      • Total lead length: 1.0 m
      • Connector: Standard miniature coaxial connector

      Bently Nevada 330104-06-14-10-02-00 is a 3300 xl 8 mm armored proximity probe configured for compatible industrial machinery monitoring applications.

      The complete order code defines the supplied mechanical, electrical and connection configuration. Verify all mating components and installation requirements before commissioning.

      The 330104-06-14-10-02-00 Bently Nevada component is supplied by Moore Automated with configuration verification and spare-parts support.
      330104-06-14-10-02-00 Bently Nevada 3300 XL Manuals(Datasheets), Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

      Technical Specifications

      • Product family: 3300 XL 8 mm Proximity Transducer System
      • Probe type: 330104 8 mm proximity probe
      • Mounting thread: M10 x 1
      • Cable armor: Armor included
      • Unthreaded length: 0.6 in (15.2 mm)
      • Case length: 1.4 in (35.6 mm)
      • Total lead length: 1.0 m
      • Connector: Standard miniature coaxial connector
      • Agency approval: No agency approval option
      • System scale factor: 7.87 V/mm (200 mV/mil)
      • Frequency response: 0 Hz to 10 kHz typical system response
      • Application: Radial vibration and axial position measurement

      Configuration Notes

      The complete 330104-06-14-10-02-00 order code identifies the supplied configuration. Confirm every field, revision, connector and mating component before replacement or commissioning.

      Application Guidance

      Follow the manufacturer installation instructions, protect connectors and cable routing, verify mounting clearances and grounding, and confirm the complete monitoring signal chain before commissioning.

      Technical notes

      The 330104-06-14-10-02-00 specifies an armored M10×1 probe with a 60 mm unthreaded section, 140 mm case, 1.0 m total length and miniature ClickLoc connector. The documented 7.87 V/mm scale factor and frequency response apply to a correctly matched 3300 XL 8 mm probe, extension cable and Proximitor Sensor chain.

      Long-Body Probe Confirmation

      Confirm the full ordering code 330104-06-14-10-02-00, including the 06 case-style prefix, 14 mm unthreaded length and all connector and approval suffixes. Provide label and mounting photographs if any code position is uncertain.

      Mechanical and System Checks

      • Full part number
        330104-06-14-10-02-00
        Check all six option groups
      • Mechanical option
        06 / 14
        Confirm 60 mm unthreaded and 140 mm case
      • Electrical length
        10 — 1.0 m
        Match system cable design
      • Connector option
        02 ClickLoc
        Check mating connector
      • Transducer family
        3300 XL 8 mm
        Confirm sensor and extension cable
      • Nameplate evidence
        Probe label and installed view
        Provide clear photos for quotation

      Quotation Input Requirements

      Provide the required quantity, complete 330104-06-14-10-02-00 code, existing probe and extension-cable labels, matched Proximitor sensor, mounting details, destination country and required delivery date so the configuration can be verified before quotation.
      PRODUCT & ORDER FAQS

      Questions buyers ask about 330104-06-14-10-02-00

      • How should the exact 330104-06-14-10-02-00 ordering code be confirmed?

        Confirm the complete code 330104-06-14-10-02-00, including the 06 unthreaded-length and 14 case-length options. Ask for the probe label and full installed-length photo when replacement clearance is critical.

      • Which system compatibility details must be checked?

        Match the probe to the specified 3300 XL 8 mm extension cable and Proximitor Sensor. The complete transducer chain must have the intended electrical length.

      • Where is this configuration normally applied?

        Designed for shaft-relative vibration and position measurement on rotating machinery within a 3300 XL 8 mm system.

      • What installation checks are required?

        Confirm M10×1 mounting, connector clearance, cable routing and the required initial gap before energizing the monitoring channel.

      • How can current availability be confirmed?

        Send the complete ordering code and quantity so Moore Automated can check current stock and lead time.

      • How is the warranty scope documented?

        The written quotation states the Moore Automated warranty scope and supplied item condition.

      • What information is needed for delivery planning?

        Provide the destination country, postal code and required delivery date so dispatch options can be quoted.

      • Which mounting dimensions should be confirmed for this long-case probe?

        Confirm the 60 mm unthreaded length, 140 mm case length, available mounting clearance and ClickLoc connector requirement before ordering.
