Features:
- 3300 XL 8 mm Proximity Transducer System
- 330195-02-12-CC-DD 3/8-24 UNF threads
- 3300 XL 8 mm Extended Temperature Range (ETR) Reverse Mount Probes
An extended temperature range (ETR) probe and ETR extension cable are available for applications in which either the probe lead or extension cable may exceed the standard 177˚C (350˚F) temperature specification. The ETR probe has an extended temperature rating for up to 218˚C (425˚F). The ETR extension cable rating is up to 260˚C (500˚F).
Both the ETR probe and cable are compatible with standard temperature probes and cables, for example, you can utilize an ETR probe with the 330130 extension cable. The ETR system uses the standard 3300 XL Proximitor Sensor. Note that when you use any ETR component as part of your system, the ETR component limits the system accuracy to the accuracy of the ETR system.
The 330195-02-12-05-05 Bently Nevada 3300 XL 8 mm (ETR) Reverse Mount Probes may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330195-02-12-05-05 3300 XL 8 mm (ETR) Reverse Mount Probes Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Model: 330195-02-12-05-05
- Warranty: One-year warranty
- Condition: Brand new, original, in stock
- Product Family: 3300 XL 8 mm Proximity Transducer System
3300 XL 8 mm Extended Temperature Range (ETR) Reverse Mount Probes
330195-02-12-Cxx-Dxx, 3/8-24 UNF threads
C: Total Length
05 : 0.5 meter (1.6 feet)
10 : 1.0 meter (3.3 feet)
15 : 1.5 meter (4.9 feet)
20 : 2.0 meters (6.6 feet)
50 : 5.0 meters (16.4 feet)
90 : 9.0 meters (29.5 feet)
D: Agency Approval
00 : Not required
05 : CSA, ATEX, IECEx approvals
Because this probe uses a 0.5-meter built-in cable, it cannot be directly connected to a Proximitor sensor. It must be used with an ETR-compliant 3300 XL 8mm extension cable to form a compatible circuit: for a standard 5.0-meter system configuration, this probe must be used with a 4.5-meter extension cable; for a standard 9.0-meter system configuration, this probe must be used with an 8.5-meter extension cable.
