      IC693PTM101

      Power Transducer Module
      In Stock
      Ships by Tuesday, June 23
      Fast Shipping Available

      Product Information:

      Power Transducer Module Processing Module
      interfaceboard (a panel mounted circuit board).
      This board interfaces betweenthe Power Transducer
      module and the input transformers (currentand potential)
      1.0 meter Interface cable that connects the moduleto
      the Interface board The Power Transducer Module
      (PTM) and Power Synchronization and Measurement
      (PSM) modulemeasure and calculate critical data for
      control of electrical power systems and synchronization of
      power grids. Both the PTM and PSM connect to user supplied
      current and potential transformers,which translate power
      grid signals to proportionate, low-level signals
      or measurement and analysis
