Features:
- Terminal Board for the Mark VIe series from GE Energy
- Terminal Board that acts as a power distribution board
- Connect the DLAN+ (ARCNET) coax cable to the BNC connector
As the core power control interface of the system, this switchboard connects and drives the MVRA and MVRF excitation controllers, Ethernet switches, and up to two PIOA input/output core components (I/O components).
This switchboard boasts extremely high industrial-grade durability and interference immunity, providing centralized and stable power support for critical automation control components such as large gas turbines or steam turbines in harsh industrial environments.
The IS200JPDVG1AAA GENERAL ELECTRIC Terminal Board may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
GENERAL ELECTRIC IS200JPDVG1AAA Terminal Board INFO(manual), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
In addition to providing pure power distribution, the IS200JPDVG1AAA integrates electronic filtering components for the system's underlying DLNA+ (ARCNET) communication network. It utilizes an onboard coaxial BNC connector layout for securely handling network telemetry data and transmits clean, filtered signals directly to the BIOA board via a high-power DC-37 pin D-sub connector.
This circuit board employs a built-in intelligent diagnostic architecture. Each critical terminal connector on the PCB contains a unique read-only electronic ID chip, which includes the factory serial number, board type, hardware version number, and physical connector coordinates (JR1/JS1/JT1). When a connected controller or I/O component starts up, it reads this chip to verify the correct physical wiring location and ensure secure hardware configuration.
