      AI-Tek Instruments 70085-1010-412
      AI-Tek Instruments 70085-1010-412

      • ISO 9001:2015 Certified

        Our quality management system covers sourcing,testing and dispatch

      • View Our Success Stories

        Real stories from real customer orders
      In Stock
      Ships by Saturday, September 5
      Fast Shipping Available
      Self-generating passive magnetic speed sensor

      70085-1010-412

      Product Information:

      70085-1010-412 is a self-generating passive magnetic speed sensor for detecting the passage of ferrous gear teeth or similar targets. It produces an AC signal whose frequency follows target speed.

      The official selection guide lists a 5/8-18 threaded body, 6.0-inch threaded length, 7.25-inch overall sensor length, wire termination, 13.4 V peak-to-peak guaranteed output and a -65 to +95 °C temperature range.

      The published output guarantee is based on a 0.030-inch air gap at 500 inches per second. Confirm target material, tooth geometry, minimum speed, air gap, load impedance, wiring and signal-input requirements before installation.

      · Product image is representative; revision or series may vary. Contact us to request a specific version.
      Get a Quote
      • One-year warranty
      • Global shipping
      • Exact-model verification
      WhatsApp: +86 180 2077 6792 Email parts team
      01


      Model Verified

      Model, revision and nameplate reviewed
      02


      Email confirmation

      You will get an email confirming that we have received your enquiry
      03


      Dedicated Account Manager

      One of our team will be in touch to confirm your part(s) specification and condition
      04


      Your quote

      You will receive a comprehensive quote tailored to your specific needs

      Technical specifications for

      70085-1010-412

      0 TECHNICAL PARAMETERS
      • Manufacturer:
        AI-Tek Instruments
      • Product Category:
        Sensor
      • Estimated shipping dimensions:
        18.42 x 1.59 x 1.59 cm
      • Weight:
        0.227 kg
      • Tariff Code:
        903180
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Product family:
        Passive Speed Sensors
      • Component type:
        Passive magnetic speed sensor
      • Model:
        70085-1010-412
      • Mounting thread:
        5/8-18
      • Threaded length:
        6.0 in
      • Overall sensor length:
        7.25 in
      • Electrical connection:
        Wires
      • Guaranteed output:
        13.4 V peak-to-peak
      • Output test condition:
        0.030 in air gap at 500 in/s
      • Operating principle:
        Self-generating magnetic pickup
      • Temperature range:
        -65 to +95 °C
      • Agency approval:
        X - as listed in the official guide
      • Application target:
        Ferrous gear teeth or similar moving target
      • Official document:
        AI-Tek Passive Sensor Selection Guide
      • Stock:
        18
      Ask for Quote
      WHAT HAPPENS NEXT?

      From enquiry to delivery

      Six clear steps show what information is required and what the written quotation will contain.
      • 01

        Find the product

        Search the part number or send an inquiry for obsolete, discontinued or hard-to-find parts.
      • 02

        Provide the details

        Share the exact part number, quantity, condition, revision, destination and any required certificates or photos.
      • 03

        Review the quotation

        Receive price, currency, condition, availability, warranty, lead time, shipping terms and quotation validity in writing.
      • 04

        Confirm the order

        Accept the quotation in writing and complete the required payment before shipment.
      • 05

        Pay by bank transfer

        Pay the full invoiced amount by bank wire in RMB/CNY, GBP, EUR or USD using the official invoice details.
      • 06

        Verify and dispatch

        The part is inspected, tested and securely packed before dispatch, with tracking provided after release.
      Request a Verified Quote
      BUYER INFORMATION

      Product condition level information

      Commercial details are confirmed in writing before payment.
      • 01

        Factory Sealed

        Unused product with the original factory seal intact; packaging age or storage marks may still be present.

        view
      • 02

        Original Pack

        Unused product in original manufacturer packaging that was not originally factory sealed.

        view
      • 03

        Factory New

        New and current product sourced through the manufacturer or authorized supply channel when expressly confirmed in the quotation.

        view

      Alternative Names

      70085 1010 412 700851010412 70085

      Information

      Overview Manuals Output Characteristics Mechanical Configuration Application Guidance

      Features:

      • Passive Magnetic Speed Sensor
      • 5/8-18 Threaded Body
      • 6.0 in Threaded Length
      • Wire Termination
      • 13.4 V Peak-to-Peak Guarantee Point

      AI-Tek Instruments 70085-1010-412 is a passive variable-reluctance speed sensor that generates an AC signal as ferrous target teeth pass its magnetic pole piece. Signal frequency corresponds to rotational speed and signal amplitude depends on speed, air gap and target geometry.

      This configuration has a 5/8-18 thread, 6.0-inch threaded length, 7.25-inch overall length and wire termination. The official guaranteed output is 13.4 V peak-to-peak at a 0.030-inch air gap and 500 inches per second.

      The 70085-1010-412 Bently Nevada passive magnetic speed sensor may be supplied and supported by Moore Automated according to the stated OEM lifecycle and confirmed stock condition.
      AI-Tek Instruments 70085-1010-412 Passive Magnetic Speed Sensor Manuals(Datasheets), Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

      Output Characteristics:

      • Self-generating variable-reluctance operation
      • 13.4 V peak-to-peak guarantee point
      • 0.030 in published test gap
      • 500 in/s published test speed
      • Output frequency follows target speed

      Available output depends on surface speed, air gap, target size and the connected load impedance.

      Mechanical Configuration:

      • 5/8-18 mounting thread
      • 6.0 in threaded length
      • 7.25 in overall length
      • Wire termination
      • -65 to +95 °C rating

      Verify the mounting depth, target path and available clearance before installing the long-body sensor.

      Application Guidance:

      • Use a ferrous toothed target
      • Minimize the air gap without contact
      • Match pole-piece size to target pitch
      • Use a high-impedance signal input
      • Check output at minimum and maximum speed

      Commission the installation by checking waveform amplitude, frequency and clearance across the full operating-speed range.

      Manuals




      Technical notes

      AI-Tek 70085-1010-412 is a 5/8-18 passive magnetic speed sensor with wire termination, 6.0-inch threaded length, 7.25-inch overall length, 13.4 V peak-to-peak guaranteed output at the stated test point and a -65 to +95 °C rating.
      PRODUCT & ORDER FAQS

      Questions buyers ask about 70085-1010-412

      • How can I identify 70085-1010-412?

        Verify the complete AI-Tek part number 70085-1010-412. The official guide identifies a 5/8-18 wire-terminated passive sensor with 6.0-inch threaded length and 7.25-inch overall length.

      • Which components are compatible with 70085-1010-412?

        It connects to instrumentation that accepts the self-generated AC output from a passive magnetic pickup. Confirm input impedance, signal amplitude, frequency range, wiring and target geometry.

      • Where is 70085-1010-412 applied?

        It measures rotational speed by sensing ferrous gear teeth or similar targets on turbines, engines, gearboxes, test stands and industrial machinery.

      • What should be checked before installing 70085-1010-412?

        Confirm the 5/8-18 mounting thread, set the air gap for the required low-speed output, align the pole piece with the target path, secure the wires and verify signal amplitude across the full speed range.

      • Is 70085-1010-412 available from stock?

        Moore Automated can confirm current inventory, the complete ordering configuration, condition and lead time before shipment.

      • What warranty applies to 70085-1010-412?

        Moore Automated provides the warranty stated in the quotation and order confirmation. Confirm the supplied condition and warranty terms before purchase.

      • How is 70085-1010-412 shipped?

        The configured order is scheduled for dispatch within 3 days from Xiamen, Fujian, China, subject to final stock and order confirmation.
