Features:
- Rugged, potted design provides ultimate reliability in extreme environments
- Fully programmable I/O including an option for two analog inputs provides exceptional flexibility in all applications
- Multiple synchronizer modes for better system implementation
The DGC-2020HD is an advanced but rugged genset control system designed for paralleling and complex load sharing schemes. With comprehensive control, metering, expandability, and protection capabilities, the DGC-2020HD is a total system solution for generator set applications. Its compact package allows users to save both space and money.
The most significant core advantage of this model lies in its advanced paralleling, load balancing, and system grid management capabilities. It is specifically designed for complex multi-unit grid connections and system segmentation, supporting peak shaving, grid power input/output control, and up to 32 levels of automatic load shedding. In practical applications, its highly robust potting design allows it to easily withstand vibrations and temperature variations in extreme environments such as oil fields, ships, or outdoor generator rooms.
The DGC-2020HD BASLER ELECTRIC Digital generator controller module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
BASLER ELECTRIC DGC-2020HD Digital generator controller manual(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
1.Capable of communicating with up to four AEM-2020’s and four CEM-2020’s, vastly increasing the I/O capabilities and overall flexibility of the DGC-2020HD and eliminating the need for external peripheral devices.
2.Selectable breaker schemes along with BESTlogic™Plus make breaker control with the DGC-2020HD simple and quick.
3.Configurable protection elements reduce the need for outside protection and external PLC’s.
4.Contains an extensive number of communication options which allows for easy integration into a wide variety of control systems.
5.Email capabilities enable the DGC-2020HD to send email alerts on selected alarms and pre-alarms.
6.Optional VRM-2020 provides generator excitation for complete voltage regulation and system control.
1.Programming Logic: Programming is performed using Basler's BESTlogic™ Plus software, which includes a built-in offline simulator, allowing for testing of circuit breaker logic and control loops without the need for physical hardware.
2.Installation Methods: Two different hardware versions are available. The standard front panel mount version features an integrated human-machine interface (HMI) and a color touchscreen.
3.The DIN rail mount version (xRxxxxxxx) requires no local HMI and is suitable for remote control of box panels.
4.Connectivity: Supports Ethernet (TCP/IP) and Modbus communication protocols, and supports automatic email notifications for system warnings or alarms.
