Features:
- SVM1-40L layout utilizing the FANUC Servo Serial Bus (FSSB) high-speed optical fiber interface for real-time axis positioning data
- Accepts a high-voltage nominal input of 283V to 325V DC from the centralized power supply, running at roughly 3.75 kW up to 6.4 kW based on workload configurations
- Delivers up to 230V AC multi-phase output, with a rated output current of 12.5 Amps dedicated to the single L-Axis loop
The FANUC A06B-6096-H104 is a precision servo drive designed specifically for industrial applications. Powered by 200-240V AC, this drive boasts a rated power of up to 40 kW and delivers exceptional performance. Its highly efficient design achieves an energy efficiency ratio of 0.98, resulting in extremely low energy loss during operation. With efficient temperature management, it operates stably within a temperature range of 0°C to +40°C, ensuring reliable operation in various environments.
It employs closed-loop torque control for precise motor performance management. Furthermore, its rated current of up to 100 A is sufficient to meet demanding operating requirements. An IP20 protection rating makes it suitable for various environments and fully considers environmental factors. Its forced air cooling system effectively controls temperature, ensuring stable performance under load. Weighing only 4.00 kg, this drive is easy to install, typically using a panel mount. Communicating with the system via the FSSB interface, it can be seamlessly integrated into control systems.
The A06B-6096-H104 General Electric Single-axis AC servo amplifier module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric A06B-6096-H104 Single-axis AC servo amplifier module (manual), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
When an abnormal situation occurs, the system will trigger the corresponding error log. These logs can be found in the standard GE FANUC Alpha maintenance manual or viewed through the CNC display interface:
Alarm 1 (AL-1): Internal cooling fan failure. The cooling components in the lower chassis have stopped rotating and need to be replaced as soon as possible.
Alarm 2 (AL-2): Control power supply undervoltage. Indicates that the internal logic power supply voltage is lower than the operating standard.
Alarm 5 (AL-5): DC bus undervoltage. Indicates that the three-phase factory-installed power supply input voltage of the shared power module has decreased.
Alarm 8, 9, or A: L-axis current abnormality. Disconnect the motor power supply cable from the U/V/W terminals to diagnose whether the fault is an internal short circuit in the driver or internal damage to the motor coils.
