Features:
- 3300 Ceramic Capped Proximity Probes
- 146054 with Modification 164523 3300 Ceramic Capped Probe, 3/8-24 UNF thread, with armor
- 146054 3300 Ceramic Capped Probe, 3/8-24 UNF thread, without armor
The 3300 Ceramic Capped Probe is a state-of-the-art solution for monitoring machinery in aggressive chemical or high-pressure environments. The alumina cap and 304 stainless steel probe case provide robust protection and increased life for applications in anhydrous ammonia or other extreme pH environments. The ceramic capped probe is compatible with the 3300 Proximitor Sensor and extension cable.
The 146054, 146055, and 164517 probes were developed for applications that expose only the front of the probe case assembly to corrosive gases and liquids. These ceramic probe assemblies prevent corrosive gases and liquids from entering the front end of the probe case.
The 146054-12-05-02-05 Bently Nevada 3300 Ceramic Capped Proximity Probes may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 146054-12-05-02-05 3300 Ceramic Capped Proximity Probes Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 146054 ceramic probe assembly features a rear connector and stainless steel tubing to prevent corrosive gases and liquids from entering the front and rear ends of the probe housing. We use helium to perform a leak test on the ceramic-to-metal connection at the front end to ensure a tight seal. The rear connector is not sealed at the factory. You can remove the tubing and connector from the probe housing and disconnect them when adjusting the clearance and installing the probe. After the probe is secured and the clearance is properly adjusted, tighten the connector to completely seal the rear end of the probe.
- Corrosive Gas and Liquid Environments: Designed for environments containing anhydrous ammonia (NH3), ammonium hydroxide (NH4OH), or extreme pH values, which typically damage standard polyphenylene sulfide (PPS) probe tips.
- High Pressure Monitoring: These probes are rated for sealing pressures up to 34 bar (500 psi), making them suitable for pressure-bearing machinery housings.
- Vibration and Position Sensing: Enables non-contact radial vibration or axial position measurement of rotating machinery such as compressors and turbines.
