Features:
- 3300 XL 50 mm Extension Cable
- 3300 XL 50 mm Proximity Transducer System
- perfluoroalkoxyethylene (PFA) insulated FluidLoc probe cable in the following total probe lengths: 1, 5 or 9 meters
The 3300 XL 50 mm probe is designed to survive the harshest steam turbine DE environments. It can continually operate and maintain its accuracy in high temperatures up to 200°C (392°F), and can withstand intermittent high temperatures up to 250°C (482°F). The 50 mm probe has both a front and rear seal which, combined with the High Temperature FluidLoc cable (standard on all 50 mm probes), prevent moisture from entering the probe tip. Special high-temperature ClickLoc connectors are also standard on the probe and extension cable.
Each probe comes with connector protectors and a disposable connector protector installation tool to ensure that the connectors remain free of contamination. The ClickLoc connector on the probe lead features a removable collar that facilitates routing the cable through tight clearances.
The 330877-080-36-00 Bently Nevada 3300 XL 50 mm Extension Cable may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330877-080-36-00 3300 XL 50 mm Extension Cable Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Model: 330877-080-36-00
- Warranty: One-year warranty
- Condition: Brand new, original, in stock
- Product Family: 3300 XL 50 mm Proximity Transducer System
3300 XL 50 mm Extension Cable
330877-Axxx-Bxx-Cxx
A: Cable Length
0 4 0: 4.0 meters (13.1 feet)
0 8 0: 8.0 meters (26.2 feet)
B: Armor and Cable
3 6: FluidLoc cable
3 7: FluidLoc ext. cable w/ armor
C: Agency Approval
0 0: No Approvals
0 5: Multiple Approvals
Each Sliding Mounting Bracket comes with:
One sliding plate
One base plate
Sliding plate securing bolts with safety wire holes
Lock washers
This 8.0-meter extension cable must be used in conjunction with a 1.0-meter integrated wire proximity probe to form a compliant 9.0-meter balanced system. If used with a 5.0-meter or 9.0-meter probe, baseline capacitance mismatch will occur in the electronic matching circuitry within the 3300 XL proximity sensor. This will result in severe crosstalk distortion, calibration scale factor offset, and inaccurate gap readings.
