Features:
- Analog Input with HART Module
- PV protection through an open wire detection diagnostic
- HART-capable, multivariable instruments and multiple modems for fast collection of control variables
The analog input module can accept high-level current or voltage inputs from transmitters and sensors.
This module supports voltage inputs for channels 13-16. When used with the CC-TAIDx1 IOTA, the CC-PAIH02 supports voltage inputs for channels 1-16. A 250-ohm load resistor for each channel is connected to the input via a jumper on the IOTA. The user should disconnect the jumper on the channel intended for voltage emitter input. For channels 13-16, the low-side input is typically connected to the system common terminal via a jumper on the IOTA. The user can disconnect this jumper to enable differential operation, but this must comply with CMV specifications.
The CC-PAIH02 51405038-376 Honeywell Analog Input modules may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell CC-PAIH02 51405038-376 Analog Input modules Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The module first receives standard industrial analog signals (e.g., 4–20 mA current or voltage signals) from the transmitter via field terminals. Signal conditioning, including filtering, isolation, and overvoltage protection, is then performed at the input stage to eliminate electromagnetic interference and ensure signal integrity. The conditioned analog signal is converted to a digital signal by a high-precision analog-to-digital converter (ADC) and transmitted to the control system processor via an internal bus.
Offshore Oil and Gas Platforms
In the offshore environment, space is limited and atmospheric corrosion is extremely high. The CC-PAIH02 is suitable for the following scenarios:
Case Objective: Monitoring a network of intelligent pressure and temperature transmitters across the entire production platform.
