Features:
- 16 channels can be used in pairs as inputs or outputs
- Intrinsically safe Ex ia IIC inputs/outputs with line fault monitoring and an LED fault and status display for each channel
- Module in Zone 1 can be replaced without having to disconnect the power supply (i.e. hot-swapped)
The 9470/32 digital input/output module for Zone 1 has 16 channels which can be used in pairs for Ex i operation as inputs for contacts and NAMUR proximity switches (EN 60947-5-6) or as outputs for indicator lamps and low-power solenoid valves. Eight inputs can be used for frequencies of up to 20 kHz, and four can be used for detecting the direction of rotation. All inputs/outputs are short-circuit proof and galvanically separated from the system.
The R. STAHL 9470/32-16-11 can be directly installed in Zone 1 hazardous areas; it features 16 highly flexible physical channels (each configurable as a NAMUR proximity switch, passive contact input, low-power solenoid valve, or indicator output); and 8 input channels supporting high-frequency counting and frequency measurement up to 20 kHz (with 4 configurable groups for identifying rotation direction).
The 9470/32-16-11 R-STAHL Digital input/output module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
R-STAHL 9470/32-16-11 Digital input/output module MANUAL(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
This module is designed for direct deployment in hazardous work areas:
Installation Environment: Certified for installation in Zone 1, Zone 2, Class I Zone 1, or Class I Zone 1.
Field Circuit Connections: Intrinsically safe Ex ia signals can be safely extended to Zones 0, 1, 2, 20, 21, and 22.
Explosion-proof Markings: ATEX: II 2 (1) G Ex ia [ia Ga] IIC T4 Gb; IECEx: Ex ia [ia Ga] IIC T4 Gb.
Hot-swappable Support: This module can be hot-swapped or replaced in hazardous areas without a hot work permit.
Intrinsically safe output specifications: Maximum voltage (U_o) = 9.8 V, Maximum current (I_o) = 10.4 mA, Maximum power (P_o) = 25.5 mW.
Power requirements: Maximum power dissipation 120 mA, peak power dissipation 2.5 W.
Operating temperature range: Reliable operation from -40°C to +75°C.
