Features:
- Supports dual CPUs and dual power supplies for redundant system architecture and improved operational reliability.
- Provides a maximum SIL 3 safety rating for applications requiring high functional safety.
- Combines a 19-inch 5U rack, 24 VDC operating voltage, IP20 protection, and natural convection cooling with an optional fan.
Industrial safety systems require reliable hardware platforms capable of supporting critical control equipment. HIMA K1409 provides a compact rack solution that accommodates essential system modules while maintaining an organized installation layout. The standard 19-inch format also simplifies integration into conventional industrial cabinets.
Redundant hardware support makes HIMA K1409 well suited for applications where continuous operation is important. Compatibility with dual CPUs and dual power supplies helps improve system availability by supporting fault-tolerant configurations. Operating from 24 VDC, the rack fits easily into many industrial automation infrastructures.
HIMA K1409 is intended for installation within protected control cabinets where IP20 protection is appropriate. Natural convection cooling reduces maintenance requirements, while an optional fan offers additional cooling flexibility for higher thermal demands. The combination of 5U height and SIL 3 capability makes HIMA K1409 suitable for a wide range of industrial safety control applications.
The K1409 HIMA safety-related systems rack may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
HIMA K1409 Safety-Related Systems Rack INFO(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The HIMA K1409 safety-related systems rack operates on the principle of centralized structural integration and electrical isolation to ensure fail-safe operation in hazardous environments. It does not process safety logic itself; instead, it acts as the vital nerve center that links, powers, and protects the active safety modules.
Emergency Shutdown Systems (ESD): Instantly halts dangerous machinery, closes safety valves, and isolates chemical pipelines during a critical system failure.
Fire and Gas Systems (F&G): Continuously monitors plant-wide flame, smoke, and toxic gas sensors to trigger automated ventilation, alarms, and suppression systems.
Burner Management Systems (BMS): Safeguards industrial boilers and furnaces by safely controlling the ignition, fuel supply, and combustion monitoring processes.
Turbomachinery Control (TMC): Protects massive high-speed rotating equipment, such as compressors and turbines, from overspeed damage or catastrophic mechanical breakdown.
