Features:
- VME Communications Interface
- General Electric's Mark VI Turbine Control System Series
- Mark VI IS200 Series produced by GE General Electric
This module is typically installed in the VME control rack, serving as the "communication hub" of the entire control system. Its primary function is to coordinate data exchange between the various input/output (I/O) boards within the VME rack and the main controller, ensuring high-speed synchronous transmission of sensor data and control commands.
This module supports a triple redundancy (TMR) architecture, distributing field data across three independent control channels (R, S, T), thereby achieving extremely high system reliability. Furthermore, it integrates status monitoring capabilities, enabling real-time detection of communication faults on the VME bus and backplane power status, providing maintenance personnel with intuitive operational feedback through panel LED indicators or host software.
The IS200VCMIH2BCD/IS215VCMIH2BC GENERAL ELECTRIC VME Communications Interface may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
GENERAL ELECTRIC IS200VCMIH2BCD/IS215VCMIH2BC VME Communications Interface INFO (manual), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The IS200VCMIH2BCD monitors the communication activity of the VME bus through its onboard high-performance microprocessor. It utilizes specific logic circuitry to encapsulate raw signals from the I/O modules and convert them into high-speed serial data packets conforming to the IONet protocol. During operation, it is responsible for addressing and synchronizing data between the various boards within the rack, ensuring that all control operations are based on the same real-time clock reference, thereby achieving precise control of large rotating machinery such as gas turbines or steam turbines.
- Bus Master Function: As the VME bus master, it manages the board IDs and coordinates all data transmissions on the VME backplane.
- Connectivity: The front panel is equipped with three IONet 10Base2 Ethernet ports and one RS-232C serial port for configuration and maintenance.
- Industrial Applications: Commonly used in power plants (including nuclear power plants) that require high-performance, rugged (conformal coating) hardware.
