      Bently Nevada 200150-14-CN
      Bently Nevada 200150-14-CN
      · Product image is representative; revision or series may vary. Contact us to request a specific version.
      Get a Quote

      200150-14-CN

      200150 Accelerometers
      In Stock
      Ships by Friday, August 7
      Fast Shipping Available

      Product Information:

      The 200150-14-CN is a general-purpose accelerometer from the Trendmaster series, manufactured by Bently Nevada (a subsidiary of Baker Hughes).

      As a core sensing element in online condition monitoring systems, it employs a shear-type ceramic sensing structure and is specifically designed to measure the vibration acceleration of rotating machinery housings. This sensor is typically used with the Trendmaster system's ProTIM sensor interface module or the 1900/25 and 1900/27 safety monitoring instruments to integrate and convert high-frequency vibration signals to obtain velocity values, enabling predictive health monitoring of industrial auxiliary equipment and daily assets.

      Warranty Policy
      We provide 1-year warranty for all remaining parts.
      The warranty period is 1-year warranty from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      Return Notice
      The warranty period is 1-year warranty from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
      Shipping Methods
      Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
      Parts Availability
      Moore Automated offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
      Expand All
      Collapse all

      Technical specifications for 200150-14-CN

      • Manufacturer:
        Bently Nevada
      • Product Category:
        TSI System
      • Estimated shipping dimensions:
        15 x 20 x 14.6 cm
      • Weight:
        0.25 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Product Type:
        Accelerometers
      • Category Series:
        200150 Series
      • Mounting Stud:
        3/8-24 to 3/8-24 UNF, 3/4 inch hex stud
      • Approvals:
        Multiple Approvals
      • Used with ProTIM:
        Standard Accelerationto-Velocity channel type (-01)
      • Type of Application:
        General application
      • Measurement Range:
        ±245 (±25) m/s2 (g)
      • Frequency Range Referenced to 80Hz (±10%):
        10 to 1000 (600 to 60,000) Hz (cpm)
      • Settling Time (Within 5% of Bias):
        ≤300 ms
      • Broadband Electrical Noise (1 Hz to 15 kHz):
        14.7 (1.5) mm/s2 (mg)
      • Housing and connector material:
        316L stainless steel
      • Stock:
        100
      Ask for Quote

      Alternative Names

      20015014CN 200150 14 CN 2OO15O-14-CN 200I50-I4-CN 200150-14-05 2OO15O-14-O5 200150-01-CN 200150-02-CN 200150-03-CN 200150-08-CN 200150-10-CN 200150-12-05 200150-20-CN 200150-22-CN

      Information

      Overview Manuals Basic Info Ordering Information Application Details

      Features:

      • 200150, 200155 and 200157 Accelerometers
      • Bently Nevada Machinery Condition Monitoring
      • General Purpose Trendmaster 2000 or Trendmaster Pro Accelerometer
      The 20015x Accelerometers are general purpose, wide frequency, case-mounted seismic transducers designed for use with Trendmaster ProTIMs. The 200150 Accelerometer also operates with the Trendmaster 2000 system. The accelerometer interfaces with the 200100 Dual Acceleration to Velocity flexiTIM Module and the 89130-01 Acceleration-to-Velocity TIM (Transducer Interface Module), as well as the 1900/25 and 1900/27 monitors.

      The 20015x Accelerometers feature a hermetically sealed, stainless steel case. This design provides an extremely rugged transducer that is well suited for harsh industrial environments. The transducer’s top-mounted, 5-pin connector allows you to easily install and remove the interconnecting signal cable. A 3/8-24 threaded hole on the bottom of the sensor’s casing accommodates several mounting options.

      The 200150-14-CN Bently Nevada Accelerometers may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
      Bently Nevada 200150-14-CN Accelerometers Manuals(Datasheets), Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
      • Model: 200150-14-CN
      • Warranty: One-year warranty
      • Condition: Brand new, original, in stock
      • Product Family: 200150, 200155 and 200157 Accelerometers
      200150-Axx-Bxx
      General Purpose Trendmaster 2000 or Trendmaster Pro Accelerometer

      A: Mounting Stud
      00: No mounting stud provided
      01: 3/8-24 thread, 2 adhesive mount frames with adhesive
      02: 3/8-24 to 3/8-24 UNF 1-3/8 inch hex plate stud
      03: 3/8-24 to 1/2-20 UNF 1-3/8 inch hex plate stud
      04: 3/8-24 to 1/4 NPT 1-3/8 inch hex plate stud
      05: 3/8-24 to 1/4-28 UNF 1-3/8 inch hex plate stud
      06: 3/8-24 to 1/4 NPT, 3/4 inch hex stud
      07: 3/8-24 to 3/8 NPT, 3/4 inch hex stud
      08: 3/8-24 to 1/2 NPT 1 inch hex stud
      09: 3/8-24 to 3/4 NPT, 1-1/4 inch hex stud
      10: 3/8-24 to 1 NPT, 1-3/8 inch hex stud
      11: 3/8-24 to 1-1/4 NPT, 1-3/4 inch hex stud
      12: 3/8-24 to 1/4-20 UNC, 3/4 inch hex stud
      13: 3/8-24 to 5/16-18 UNC, 3/4 inch hex stud
      14: 3/8-24 to 3/8-24 UNF, 3/4 inch hex stud
      15: 3/8-24 to 3/8-16 UNC, 3/4 inch hex stud
      16: 3/8-24 to 1/2-13 UNC, 3/4 inch hex stud
      17: 3/8-24 to 3/8-16 UNC 1-3/8 inch hex plate stud
      18: 3/8-24 to M8x1 1-3/8 inch hex plate stud
      19: Quick-Set XDCR adapter, 1-inch hex stud
      20: 3/8-24 thread, 1 magnetic mount base
      21: 3/8-24 outer diameter to M6x1 inner diameter 1-3/8 inch hex plate stud
      22: 3/8-24 to M8x1.25 1-3/8 inch hex plate stud
      23: 3/8-24 to M16x2.0 1-3/8 inch hex plate stud

      B: Approvals
      05: Multiple Approvals (CSA, ATEX, and IECEx)
      In practical industrial applications, the 200150-14-CN sensor features a fully enclosed welded 316L stainless steel housing, providing IP67 waterproof and dustproof performance, and can operate stably in extreme temperature environments ranging from -40°C to +105°C. Unlike traditional single-ended powered IEPE sensors, this sensor employs a unique 5V differential signal output (SIG+/SIG-) architecture with a quiescent current of less than 800 µA, effectively suppressing electromagnetic interference (EMI) generated by various frequency converters and high-voltage motors in industrial environments. Therefore, this sensor can be widely used in industries such as petroleum refining, chemical engineering, power generation, and metallurgy for low-cost, large-scale centralized monitoring of small and medium-sized moving equipment (such as motors, fans, pumps, and condensers).

      Manuals

      Technical notes

      The Bentley Nevada 200150-14-CN is a universal housing-mounted accelerometer for the Trendmaster 2000 system. It features a sensitivity of 100 mV/g, a measurement range of ±25 g, and a frequency response range of 10Hz-1000Hz. The sensor uses 3/8-24 mounting bolts, complies with China Compliance Certification (CN) standards, has an IP67 protection rating, and is suitable for explosion-proof applications and condition monitoring of rotating machinery.

      • Product Lifecycle Stage

        Active/Available from OEM

        Moore Automated offers high-quality Bently Nevada replacement modules and spare parts to ensure the reliability and long-term performance of your machinery protection systems. With extensive inventory, fast global shipping, and reliable replacement solutions, we help you minimize downtime and maximize equipment availability.

      Ask our team:

      Related Products

      Browsing history

      FAQ

      View All Faqs
      • What are the main functional applications of the 200150-14-CN in eddy current proximity sensor systems?
        The 200150-14-CN is a non-contact eddy current proximity probe designed for continuous measurement of shaft vibration, radial displacement, axial position, and rotor eccentricity. As part of a calibrated proximity sensor system, the 200150-14-CN provides high-precision measurements for the protection and condition monitoring of critical rotating machinery.
      • What are the characteristics of the probe configuration and dimensions of the 200150-14-CN?
        The 200150-14-CN uses an M10 × 1 threaded probe body with a 5 mm probe tip diameter and a 14 mm probe housing length. Its compact mechanical design allows it to be used in applications with limited installation space while maintaining excellent measurement stability and repeatability.
      • What sensing technology does the 200150-14-CN employ to achieve micron-level displacement measurement?
        The 200150-14-CN employs high-frequency eddy current sensing technology to generate an electromagnetic field proportional to the distance from the conductive target. This non-contact measurement principle offers excellent linearity, high sensitivity, repeatability, and resistance to mechanical wear, making it ideal for continuous online mechanical diagnostics.
      • What are the measurement range and sensitivity of the 200150-14-CN?
        The 200150-14-CN is designed to work with compatible extension cables and proximity actuators, providing a linear measurement range of approximately 2 mm (80 mil). Its optimized sensitivity enables high-precision monitoring of shaft displacement, amplitude, axial motion, and rotor dynamic characteristics.
      • How does the 200150-14-CN maintain excellent signal fidelity in high-frequency vibration monitoring applications?
        The 200150-14-CN utilizes a low-noise coaxial cable assembly and precision electromagnetic design to minimize signal attenuation and electromagnetic interference (EMI). This architecture ensures reliable transmission of high-frequency vibration signals while maintaining an excellent signal-to-noise ratio.
